INOS
|
The inos error header file. More...
Go to the source code of this file.
Classes | |
| struct | SINOSError |
| struct | SINOSErrorFlag |
| class | CINOSError |
| Exception class associated with an INOS error code. More... | |
Macros | |
| #define | INOSERROR(label, code, text) uint32 label = code; |
| #define | INOS_RETURN(aError) return aError |
| #define | INOS_ERRORS(X) |
The inos error header file.
project : INOS language : Gnu C++ system : Indel targets
This class provides the error codes defined by INOS (or McRobot) not defined by customers. The errors must be in the range 0x40000000..0x40FFFFFF as specified in the inco_32 documentation. Note: Errors defined by customers must be in the range 0x80000000..0x80FFFFFF
| uint32 INOS_CONFIG_GENERAL = 0x40410000 |
"General configuration error"
| uint32 INOS_CONFIG_INVALID_ATTRIBUTE_REQUESTED = 0x40410001 |
"Invalid attribute requested"
| INOS_MCMSG_FLAG_NONE uint32 INOS_CONFIG_UNKNOWN_DISTRIBUTIONBOARD_REQUESTED = 0x40410002 |
"Unknown distrbution board requested"
| uint32 INOS_COPBUS_FAILED_TO_READ_CONSISTENT_PORT_VALUE = 0x40400002 |
"Failed to read consistent COP module port value"
| uint32 INOS_COPBUS_FAILED_TO_WRITE_MODULE_VARIABLE = 0x40400001 |
"Failed to write COP module variable"
| uint32 INOS_DATA_ATTRIBUTE_DUPLICATE = 0x4080000A |
"Duplicate attribute detected"
| uint32 INOS_DATA_ATTRIBUTE_IS_NUMBER = 0x40800009 |
"Attribute is a number"
| uint32 INOS_DATA_ATTRIBUTE_IS_STRING = 0x40800008 |
"Attribute is a string"
| uint32 INOS_DATA_ATTRIBUTE_NOT_FOUND = 0x40800004 |
"Data attribute not found"
| uint32 INOS_DATA_ID_NOT_FOUND = 0x40800001 |
"Data id not found"
| uint32 INOS_DATA_INVALID_PATH_GIVEN = 0x4080000F |
"Invalid INCO path given"
| uint32 INOS_DATA_ITEM_NOT_FOUND = 0x4080000E |
"Data item not found"
| uint32 INOS_DATA_LOCK_NOT_YET_SUPPORTED = 0x40810001 |
"Data lock mechanism not yet supported"
| uint32 INOS_DATA_LOCK_PENDING = 0x40810002 |
"Data lock pending"
| uint32 INOS_DATA_LOCK_UNKNOWN_ID = 0x40810003 |
"Unknown lock id given"
| uint32 INOS_DATA_OBJECT_DUPLICATE = 0x4080000C |
"Duplicate object detected"
| uint32 INOS_DATA_OBJECT_ID_IS_PROPERTY = 0x4080000D |
"Given object id is a property"
| uint32 INOS_DATA_OBJECT_NOT_FOUND = 0x40800002 |
"Data object not found"
| uint32 INOS_DATA_PROPERTY_DUPLICATE = 0x4080000B |
"Duplicate property detected"
| uint32 INOS_DATA_PROPERTY_ID_IS_NUMBER = 0x40800007 |
"Given id is a number"
| uint32 INOS_DATA_PROPERTY_ID_IS_OBJECT = 0x40800005 |
"Given id is an object"
| uint32 INOS_DATA_PROPERTY_ID_IS_STRING = 0x40800006 |
"Given id is a string"
| uint32 INOS_DATA_PROPERTY_NOT_FOUND = 0x40800003 |
"Data property not found"
| uint32 INOS_DT2_INVALID_RECORD_NUMBER = 0x40830003 |
"Invalid record number given"
| uint32 INOS_DT2_STRUCTURE_SIZE_MISMATCH = 0x40830002 |
"Given structure size doesn't match internal one"
| uint32 INOS_DT2_UNKNOWN_TABLE_NAME = 0x40830001 |
"Unknown table name requested"
| uint32 INOS_ERR_ALREADY_EXISTING = 0x40200004 |
Indicates that some item already exists with the given name/id and therefore cannot be created/added. Example: container lookup
"Item already exists"
| uint32 INOS_ERR_BAD_STATE = 0x40200002 |
Indicates that the requested operation is not permitted in the current state. Example: precondition check, default-case in switch statement
"Operation not permitted in current state"
| uint32 INOS_ERR_CANCELLED = 0x40200008 |
Indicates that the requested operation was cancelled due to an external event. Example: User cancelled an ongoing task
"Operation cancelled"
| uint32 INOS_ERR_FAILED = 0x40200000 |
Indicates a general failure that is not further specified. Example: A function returning false
"Operation failed"
| uint32 INOS_ERR_INTERNAL = 0x40200009 |
Indicates that an operation failed due to unexpected circumstances or invalid state. Example: Class invariant violated
"An internal error occurred"
| uint32 INOS_ERR_INVALID_ARG = 0x40200003 |
Indicates that an operation was initiated with invalid arguments. Example: precondition check
"Invalid argument"
| uint32 INOS_ERR_NOT_FOUND = 0x40200005 |
Indicates that some item does not exists with the given name/id. Example: container lookup
"Item not found"
| uint32 INOS_ERR_NOT_SUPPORTED = 0x40200001 |
Indicates that the requested operation is not supported. Example: default-case in switch statement
"Operation not supported"
| uint32 INOS_ERR_OUT_OF_RES = 0x40200006 |
Indicates that the requested operation cannot be performed because the required memory/array slot/disk space is not available. Example: Calling new/malloc, adding an item to a fixed-size array
"Out of resources"
| uint32 INOS_ERR_TIMEOUT = 0x40200007 |
Indicates that the requested operation timed out. Example: Waiting for a resource to be available
"Operation timed out"
| uint32 INOS_ETHERCAT_CMD_GENERAL = 0x40510000 |
"General Ethercat command error"
| uint32 INOS_ETHERCAT_COE_EXPEDITED_ONLY = 0x40530003 |
"Only expedited transfer supported (<= 4 bytes)"
| uint32 INOS_ETHERCAT_COE_GENERAL = 0x40530000 |
"General Ethercat CoE error"
| uint32 INOS_ETHERCAT_COE_MORE_DATA_THAN_EXPECTED = 0x40530004 |
"Got more data than expected"
| uint32 INOS_ETHERCAT_COE_SDO_ABORT = 0x40530005 |
"Received an SDO abort"
| uint32 INOS_ETHERCAT_COE_SEGMENTED_TRANSFER_NOT_SUPPORTED = 0x40530002 |
"Segmented transfer not supported"
| uint32 INOS_ETHERCAT_COE_UNEXPECTED_RESULT = 0x40530001 |
"Received unexpected CoE result"
| uint32 INOS_ETHERCAT_GENERAL = 0x40500000 |
"General Ethercat error"
| uint32 INOS_ETHERCAT_MBX_EMERGENCY_REQUEST = 0x40520005 |
"Mailbox emergency request"
| uint32 INOS_ETHERCAT_MBX_EOE_NOT_SUPPORTED = 0x40520004 |
"EoE not supported"
| uint32 INOS_ETHERCAT_MBX_GENERAL = 0x40520000 |
"General Ethercat mailbox error"
| uint32 INOS_ETHERCAT_MBX_NOT_AVAILBALE = 0x40520001 |
"No mailbox available"
| uint32 INOS_ETHERCAT_MBX_OUT_EMPTY_TIMEOUT = 0x40520002 |
"Timeout waiting for OUT mailbox"
| uint32 INOS_ETHERCAT_MBX_OUT_SEND = 0x40520003 |
"Error writing to OUT mailbox"
| uint32 INOS_ETHERCAT_UNKNOWN_SLAVE_ADDRESS = 0x40500001 |
"Unknown slave address given"
| uint32 INOS_FPGA_UPDATE_NECESSARY = 0x40822001 |
"FPGA or bootloader too old for this system, please update first"
| INOS_MCMSG_FLAG_NONE uint32 INOS_GINLINK_FAILED_TO_READ_DESCRIPTOR = 0x40420001 |
"Failed to read GinLink module descriptor"
| uint32 INOS_GINLINK_TRANSMIT_DATA_BUFFER_TOO_SMALL = 0x40420002 |
"Cyclic transmit data buffer too small"
| uint32 INOS_IMAGE_COMPRESS_FAILED = 0x40820007 |
"Failed to compress image data"
| uint32 INOS_IMAGE_COMPRESS_TYPE_NOT_SUPPORTED = 0x40820006 |
"Compression type not supported"
| uint32 INOS_IMAGE_COMPRESS_TYPE_UNKNOWN = 0x40820005 |
"Unknown compression type"
| uint32 INOS_IMAGE_DATA_CRC_WRONG = 0x40820004 |
"Wrong data crc detected"
| uint32 INOS_IMAGE_DATA_JSON_PARSING_FAILED = 0x40820010 |
"Parsing data json failed"
| uint32 INOS_IMAGE_DATA_SIGNATURE_INVALID = 0x4082001A |
"Invalid image signature detected"
| uint32 INOS_IMAGE_DATA_SIGNATURE_NOT_FOUND = 0x40820018 |
"Image signature not found"
| uint32 INOS_IMAGE_DATA_XML_OBJECT_EXISTS = 0x4082000D |
"Creation failed, object already exists"
| uint32 INOS_IMAGE_DATA_XML_PARSING_FAILED = 0x4082000C |
"Parsing data xml failed"
| uint32 INOS_IMAGE_DT2_GENERAL_PARSE_ERROR = 0x40870000 |
"General parse error"
| uint32 INOS_IMAGE_HEADER_CRC_WRONG = 0x40820002 |
"Wrong header crc detected"
| uint32 INOS_IMAGE_HEADER_INVALID_MAGIC_NUMBER = 0x40820001 |
"Invalid magic number"
| uint32 INOS_IMAGE_HEADER_LINE_NOT_FOUND = 0x40820003 |
"Requested header line not found"
| uint32 INOS_IMAGE_HX_GENERAL_PARSE_ERROR = 0x40880000 |
"General HX file parse error"
| uint32 INOS_IMAGE_INVALID_OBJECT_INDEX = 0x4082000B |
"Invalid object index requested"
| uint32 INOS_IMAGE_INVALID_REFERENCE_INDEX = 0x4082000A |
"Invalid reference index requested"
| uint32 INOS_IMAGE_LOADER_BOOT_NOT_SUPPORTED = 0x40821009 |
"Boot from image not supported"
| uint32 INOS_IMAGE_LOADER_BOOTLOADER_TOO_OLD = 0x40821007 |
"Bootloader too old to load INOS images"
| uint32 INOS_IMAGE_LOADER_FLASH_NO_DEVICE = 0x40821001 |
"No flash device available"
| uint32 INOS_IMAGE_LOADER_FLASH_READ_FAILED = 0x40821008 |
"Failed to reading from flash"
| uint32 INOS_IMAGE_LOADER_FLASH_VERIFY_FAILED = 0x40821003 |
"Flash verification failed. Do not turn off power and try again!"
| uint32 INOS_IMAGE_LOADER_FLASH_WRITE_FAILED = 0x40821002 |
"Failed to write flash"
| uint32 INOS_IMAGE_LOADER_IMAGE_NO_NAME = 0x40821006 |
"Image name missing"
| uint32 INOS_IMAGE_LOADER_IMAGE_TOO_LARGE = 0x40821004 |
"Image too large to fit in flash"
| uint32 INOS_IMAGE_LOADER_PRODUCT_ID_MISMATCH = 0x40821005 |
"Product Id mismatch. Did you select the wrong target/build configuration?"
| uint32 INOS_IMAGE_LOADER_TRANSFER_STOPPED_BY_CLIENT = 0x4082100A |
"Image transfer stopped by client before completed"
| uint32 INOS_IMAGE_MOVEPATH_XML_INVALID_AXIS_NAME = 0x40820016 |
"Invalid axis name detected in given xml"
| uint32 INOS_IMAGE_MOVEPATH_XML_INVALID_FORMAT = 0x40820017 |
"Invalid format detected in given xml"
| uint32 INOS_IMAGE_MOVEPATH_XML_NO_PATH = 0x40820014 |
"No movepath found in given xml"
| uint32 INOS_IMAGE_MOVEPATH_XML_NRBPOINT_INVALID = 0x40820015 |
"Invalid nurb point detected in given xml"
| uint32 INOS_IMAGE_MOVEPATH_XML_PARSING_FAILED = 0x40820013 |
"Parsing movepath xml failed"
| uint32 INOS_IMAGE_MULTIIMAGE_SIZE_TO_SMALL = 0x4082000F |
"Multiimage size to small"
| uint32 INOS_IMAGE_NO_KEY_PROVIDED = 0x40820019 |
"No public key for signature check provided"
| uint32 INOS_IMAGE_NOT_BOOTABLE = 0x40820012 |
"Given image not bootable"
| uint32 INOS_IMAGE_NOT_YET_IMPLEMENTED = 0x40820011 |
"Not yet implemented"
| uint32 INOS_IMAGE_UNCOMPRESS_FAILED = 0x40820008 |
"Failed to uncompress image data"
| uint32 INOS_IMAGE_UNCOMPRESS_SIZE_MISMATCH = 0x40820009 |
"Uncompressed data size mismatch"
| uint32 INOS_IMAGE_UNKNOWN_CONTENT_TYPE = 0x4082000E |
"Unknown image content type requested"
| uint32 INOS_JSON_GENERAL = 0x40840000 |
"General JSON error"
| uint32 INOS_JSON_INCOMPLETE = 0x40840003 |
"The string is not a full JSON packet, more bytes expected"
| uint32 INOS_JSON_INVALID_ARRAY_SYNTAX = 0x40840025 |
"Invalid JSON array : ',' or ']' expected after value "
| uint32 INOS_JSON_INVALID_CHARACTER = 0x40840002 |
"Invalid character inside JSON string"
| uint32 INOS_JSON_INVALID_ESCAPE_CHARACTER = 0x40840005 |
"Invalid escape character inside JSON string"
| uint32 INOS_JSON_INVALID_OBJECT_SYNTAX = 0x40840024 |
"Invalid JSON object : ',' or '}' expected after value "
| uint32 INOS_JSON_INVALID_VALUE = 0x40840023 |
"The JSON parser failed: Not a valid value"
| uint32 INOS_JSON_JUNK = 0x40840004 |
"The string contains junk data after its root element"
| uint32 INOS_JSON_KEY_IS_NOT_A_STRING = 0x40840016 |
"The expected key token is not a 'string' type"
| uint32 INOS_JSON_KEY_NOT_FOUND = 0x40840010 |
"Requested key not found"
| uint32 INOS_JSON_KEY_WITHOUT_VALUE = 0x40840011 |
"The requested key has no value (':' followed by value expected)"
| uint32 INOS_JSON_NOT_ENOUGH_TOKENS = 0x40840001 |
"Not enough tokens were provided"
| uint32 INOS_JSON_NUMBER_PARSER_INVALID_NUMBER = 0x40840020 |
"The JSON number parser failed: Not a valid number"
| uint32 INOS_JSON_NUMBER_PARSER_TRAILING_CRAP = 0x40840021 |
"The JSON number parser failed: Non-number chars were detected at end of the number"
| uint32 INOS_JSON_NUMBER_TOO_BIG = 0x40840022 |
"The JSON number parser failed: Number is too big for destination type"
| uint32 INOS_JSON_RESULT_BUFFER_TO_SMALL = 0x40840012 |
"Given result buffer to small"
| uint32 INOS_JSON_STRING_TO_LONG = 0x40840006 |
"String value to long for available buffer"
| uint32 INOS_JSON_TOKEN_HAS_NOT_ONE_CHILD = 0x40840018 |
"The JSON token was expected to have exactly 1 child, but it didn't"
| uint32 INOS_JSON_TOKEN_NOT_A_NUMBER = 0x40840015 |
"Token is not a 'number' type"
| uint32 INOS_JSON_TOKEN_NOT_A_OBJECT = 0x40840013 |
"Token is not a 'object' type"
| uint32 INOS_JSON_TOKEN_NOT_A_STRING = 0x40840014 |
"Token is not a 'string' type"
| uint32 INOS_JSON_TOKEN_OBJECT_EMPTY = 0x40840017 |
"The JSON object is empty"
| uint32 INOS_JSON_VALUE_IS_NOT_A_BOOL = 0x40840019 |
"Token is not a 'boolean' type"
| uint32 INOS_LVDT_CALIBRATION_FAILED = 0x40860002 |
"LVDT channel calibration failed"
| uint32 INOS_LVDT_GENERAL = 0x40860000 |
"General LVDT error"
| uint32 INOS_LVDT_UNKNOWN_CHANNEL = 0x40860001 |
"Unknown LVDT channel given"
| uint32 INOS_MCMSG_CODE_BUS_ERROR_COUNTER = 0x40120001 |
"Fieldbus error occurred"
| uint32 INOS_MCMSG_CODE_BUS_HOOK_CATEGORIES_INVALID = 0x40120105 |
"Invalid number of categories given"
| uint32 INOS_MCMSG_CODE_BUS_HOOK_CATEGORY_INVALID = 0x40120106 |
"Invalid category given"
| uint32 INOS_MCMSG_CODE_BUS_HOOK_CATEGORY_INVALID_CYCLETIME = 0x40120107 |
"Invalid category cycletime given"
| uint32 INOS_MCMSG_CODE_BUS_HOOK_CATEGORY_NO_VALID_FOUND = 0x40120108 |
"No valid category found"
| uint32 INOS_MCMSG_CODE_BUS_HOOK_COREBASE_INVALID = 0x40120102 |
"Invalid core base given"
| uint32 INOS_MCMSG_CODE_BUS_HOOK_COREID_INVALID = 0x40120103 |
"Invalid core id given"
| uint32 INOS_MCMSG_CODE_BUS_HOOK_CORES_INVALID = 0x40120101 |
"Invalid number of cores given"
| uint32 INOS_MCMSG_CODE_BUS_HOOK_CYCLENUMBER_INVALID = 0x40120109 |
"Invalid cyclenumber given"
| uint32 INOS_MCMSG_CODE_BUS_HOOK_CYCLETIME_INVALID = 0x4012010A |
"Invalid cycletime given"
| uint32 INOS_MCMSG_CODE_BUS_HOOK_EXCEPTION_NOT_SUPPORTED = 0x40120113 |
"Exception handling not supported"
| uint32 INOS_MCMSG_CODE_BUS_HOOK_GROUPID_INVALID = 0x40120104 |
"Invalid group id given (only 0..3 allowed)"
| uint32 INOS_MCMSG_CODE_BUS_HOOK_HANDLER_INVALID = 0x4012010C |
"Invalid handler given"
| uint32 INOS_MCMSG_CODE_BUS_HOOK_HOOKID_INVALID = 0x40120110 |
"Invalid hook id given"
| uint32 INOS_MCMSG_CODE_BUS_HOOK_HOOKS_INVALID = 0x4012010D |
"Invalid number of hooks given"
| uint32 INOS_MCMSG_CODE_BUS_HOOK_HOOKS_POWER_OF_TWO = 0x4012010E |
"Number of hooks has to be a power of 2"
| uint32 INOS_MCMSG_CODE_BUS_HOOK_NO_MORE_HOOKS_LEFT = 0x4012010F |
"No more hooks left"
| uint32 INOS_MCMSG_CODE_BUS_HOOK_NODE_LEAK_DETECTED = 0x40120111 |
"Hook node leak at shutdown detected"
| uint32 INOS_MCMSG_CODE_BUS_HOOK_ORDER_INVALID = 0x4012010B |
"Invalid order given"
| uint32 INOS_MCMSG_CODE_BUS_HOOK_ORDER_MISMATCH = 0x40120112 |
"Hook order mismatch detected"
| uint32 INOS_MCMSG_CODE_BUS_HOOK_WRONG_STATE = 0x40120100 |
"Hooks handler in wrong state"
| uint32 INOS_MCMSG_CODE_BUS_LINK_DOWN = 0x40120003 |
"Fieldbus link down"
| uint32 INOS_MCMSG_CODE_BUS_MAINTENANCE = 0x40120007 |
"Fieldbus maintenance overrun detected"
| uint32 INOS_MCMSG_CODE_BUS_OVERRUN = 0x40120002 |
"Fieldbus overrun detected"
| uint32 INOS_MCMSG_CODE_BUS_POST_OVERRUN = 0x40120004 |
"Fieldbus post overrun detected"
| uint32 INOS_MCMSG_CODE_BUS_RESCAN = 0x40120006 |
"Fieldbus rescan happened"
| uint32 INOS_MCMSG_CODE_BUS_SYNCCORES_TIMEOUT = 0x40120005 |
"Timeout while syncing cores"
| uint32 INOS_MCMSG_CODE_COORD_COMMAND_IGNORED = 0x40010008 |
"Command ignored"
| uint32 INOS_MCMSG_CODE_COORD_MAX_NESTED = 0x40010009 |
"Max. allowed nesting level reached"
| uint32 INOS_MCMSG_CODE_COORD_NO_LOCAL_SUPPORT = 0x4001000A |
"No local variable support"
| uint32 INOS_MCMSG_CODE_COORD_UNKNOWN_DATA = 0x40010005 |
"Unknown data"
| uint32 INOS_MCMSG_CODE_COORD_UNKNOWN_JOB = 0x40010004 |
"Unknown job"
| uint32 INOS_MCMSG_CODE_COORD_UNKNOWN_LABEL = 0x40010001 |
"Unknown label"
| uint32 INOS_MCMSG_CODE_COORD_UNKNOWN_MODULE = 0x40010002 |
"Unknown module"
| uint32 INOS_MCMSG_CODE_COORD_UNKNOWN_SCRIPT = 0x40010003 |
"Unknown script"
| uint32 INOS_MCMSG_CODE_COORD_VAR_FAILED = 0x40010200 |
"Variable access failed"
| uint32 INOS_MCMSG_CODE_COORD_VAR_MAX = 0x40010204 |
"Variable maximum reached"
| uint32 INOS_MCMSG_CODE_COORD_VAR_MIN = 0x40010203 |
"Variable minimum reached"
| uint32 INOS_MCMSG_CODE_COORD_VAR_NOT_FOUND = 0x40010201 |
"Variable not found"
| uint32 INOS_MCMSG_CODE_COORD_VAR_READ_ONLY = 0x40010202 |
"Variable is read only"
| uint32 INOS_MCMSG_CODE_DPAA2_QBMAN_ACQUIRE_ECC_ERROR = 0x403C0100 |
"DPAA2 QBMAN stockpile ECC error occured while acquiring buffers, buffer pointers may be corrupt"
| uint32 INOS_MCMSG_CODE_DPAA2_QBMAN_ACQUIRE_INVALID = 0x403C0101 |
"DPAA2 QBMAN Error, unrecognized, invalid, or unauthorized (in a portal with BDI=0) command was received."
| uint32 INOS_MCMSG_CODE_DPAA2_QBMAN_ACQUIRE_NUMBER = 0x403C0102 |
"DPAA2 QBMAN Acquire didn't get requested number of buffers"
| uint32 INOS_MCMSG_CODE_DPAA2_QBMAN_ACQUIRE_UNKNOWN = 0x403C0103 |
"DPAA2 QBMAN unknown error occured"
| uint32 INOS_MCMSG_CODE_DPAA2_QBMAN_AT_ADDR_OUTSIDE_RANGE = 0x403C0113 |
"DPAA2 QBMAN ADDR supplied in the command is outside the valid range for this SoC"
| uint32 INOS_MCMSG_CODE_DPAA2_QBMAN_AT_ALREADY_EXISTS = 0x403C010E |
"DPAA2 QBMAN An authorization table entry already exists"
| uint32 INOS_MCMSG_CODE_DPAA2_QBMAN_AT_INSERT_FAILED = 0x403C010F |
"DPAA2 QBMAN Authorization table insert failed. Please re-try the command with a different VRID"
| uint32 INOS_MCMSG_CODE_DPAA2_QBMAN_AT_INVALID = 0x403C0110 |
"DPAA2 QBMAN Error, unrecognized, invalid, or unauthorized (in a portal with BDI=0) command was received.."
| uint32 INOS_MCMSG_CODE_DPAA2_QBMAN_AT_NOT_FOUND = 0x403C0112 |
"DPAA2 QBMAN No authorization table entry was found for the specified TYPE, ICID, and VRID"
| uint32 INOS_MCMSG_CODE_DPAA2_QBMAN_AT_UNKNOWN = 0x403C0111 |
"DPAA2 QBMAN unknown error occured"
| uint32 INOS_MCMSG_CODE_DPAA2_QBMAN_FQ_INVALID = 0x403C0109 |
"DPAA2 QBMAN Error, unrecognized, invalid, or unauthorized (in a portal with BDI=0) command was received.."
| uint32 INOS_MCMSG_CODE_DPAA2_QBMAN_FQ_INVALID_FQID = 0x403C0107 |
"DPAA2 QBMAN Error, command failed due to FQID"
| uint32 INOS_MCMSG_CODE_DPAA2_QBMAN_FQ_INVALID_STATE = 0x403C0108 |
"DPAA2 QBMAN Error, command failed due to invalid FQ state"
| uint32 INOS_MCMSG_CODE_DPAA2_QBMAN_FQ_UNKNOWN = 0x403C010A |
"DPAA2 QBMAN unknown error occured"
| uint32 INOS_MCMSG_CODE_DPAA2_QBMAN_QUERY_INVALID = 0x403C0105 |
"DPAA2 QBMAN Error, unrecognized, invalid, or unauthorized (in a portal with BDI=0) command was received."
| uint32 INOS_MCMSG_CODE_DPAA2_QBMAN_QUERY_INVALID_BPID = 0x403C0104 |
"DPAA2 QBMAN Error, command failed due to invalid BPID"
| uint32 INOS_MCMSG_CODE_DPAA2_QBMAN_QUERY_UNKNOWN = 0x403C0106 |
"DPAA2 QBMAN unknown error occured"
| uint32 INOS_MCMSG_CODE_DPAA2_QBMAN_WQ_INVALID = 0x403C010C |
"DPAA2 QBMAN Error, unrecognized, invalid, or unauthorized (in a portal with BDI=0) command was received.."
| uint32 INOS_MCMSG_CODE_DPAA2_QBMAN_WQ_INVALID_CHANNEL = 0x403C010B |
"DPAA2 QBMAN Error, an invalid channel number was specified in the command"
| uint32 INOS_MCMSG_CODE_DPAA2_QBMAN_WQ_UNKNOWN = 0x403C010D |
"DPAA2 QBMAN unknown error occured"
| uint32 INOS_MCMSG_CODE_DPAA2_RESOURCE_COMMAND_AUTH_ERROR = 0x403C0003 |
"DPAA2 Command Authentication error (illegal object-portal-icid combination)"
| uint32 INOS_MCMSG_CODE_DPAA2_RESOURCE_COMMAND_BUSY = 0x403C000A |
"DPAA2 Command Busy (operation cannot be completed temporarily)"
| uint32 INOS_MCMSG_CODE_DPAA2_RESOURCE_COMMAND_CONFIG_ERROR = 0x403C0006 |
"DPAA2 Command Configuration error (invalid/conflicting parameters)"
| uint32 INOS_MCMSG_CODE_DPAA2_RESOURCE_COMMAND_DMA_IO_ERROR = 0x403C0005 |
"DPAA2 Command DMA or I/O error"
| uint32 INOS_MCMSG_CODE_DPAA2_RESOURCE_COMMAND_INVALID_STATE = 0x403C000C |
"DPAA2 Command Invalid state (may indicate incorrect calling sequence)"
| uint32 INOS_MCMSG_CODE_DPAA2_RESOURCE_COMMAND_NO_MEMORY = 0x403C0009 |
"DPAA2 Command No memory available for completing the command"
| uint32 INOS_MCMSG_CODE_DPAA2_RESOURCE_COMMAND_NO_PRIVILIEGE = 0x403C0004 |
"DPAA2 Command No privilege (operation not permitted for current user)"
| uint32 INOS_MCMSG_CODE_DPAA2_RESOURCE_COMMAND_NO_RESOURCE = 0x403C0008 |
"DPAA2 Command No DPAA2 resources for completing the command"
| uint32 INOS_MCMSG_CODE_DPAA2_RESOURCE_COMMAND_READY = 0x403C0001 |
"DPAA2 Command is ready for processing (must be set by the submitter)"
| uint32 INOS_MCMSG_CODE_DPAA2_RESOURCE_COMMAND_STATUS = 0x403C0000 |
"DPAA2 Command ended successfully (set by MC on successful command completion)"
| uint32 INOS_MCMSG_CODE_DPAA2_RESOURCE_COMMAND_TIMED_OUT = 0x403C0007 |
"DPAA2 Command timed out (unexpected long execution time)"
| uint32 INOS_MCMSG_CODE_DPAA2_RESOURCE_COMMAND_TIMEOUT = 0x403C0010 |
"DPAA2 Command timeout"
| uint32 INOS_MCMSG_CODE_DPAA2_RESOURCE_COMMAND_UNSUPPORTED = 0x403C000B |
"DPAA2 Command Unsupported/unknown operation"
| uint32 INOS_MCMSG_CODE_DPAA2_RESOURCE_INVALID_TOKEN = 0x403C0011 |
"DPAA2 Command Got invalid token"
| uint32 INOS_MCMSG_CODE_GINHMI_OFF_FAILED = 0x40060001 |
"Switching off GIN-GMI failed due to a communication error"
| uint32 INOS_MCMSG_CODE_GINHMI_ON_FAILED = 0x40060000 |
"Switching on GIN-GMI failed due to a communication error"
| uint32 INOS_MCMSG_CODE_GINHMI_RESET_FAILED = 0x40060002 |
"Resetting GIN-GMI failed due to a communication error"
| uint32 INOS_MCMSG_CODE_INCO_DBG_BASE = 0x40150600 |
"Generic INCO debug error"
| uint32 INOS_MCMSG_CODE_INCO_DBG_BKP_NO_SPACE = 0x40150615 |
"No more breakpoint space left"
| uint32 INOS_MCMSG_CODE_INCO_DBG_BKPT_NOT_ENOUGH_MEM = 0x40150609 |
"Not enough memory to set breakpoint"
| uint32 INOS_MCMSG_CODE_INCO_DBG_BUFFER_TO_SMALL = 0x4015060D |
"Buffer is to small to store all data. Data has been truncated"
| uint32 INOS_MCMSG_CODE_INCO_DBG_BUFFER_TO_SMALL2 = 0x40150612 |
"Buffer is to small to store all data. No data returned"
| uint32 INOS_MCMSG_CODE_INCO_DBG_DATA_VALUE_TO_BIG = 0x40150616 |
"Requested value does not fit into 32 bit"
| uint32 INOS_MCMSG_CODE_INCO_DBG_EMPTY_CACHE = 0x40150613 |
"No cache information available"
| uint32 INOS_MCMSG_CODE_INCO_DBG_HARD_RESET_NOT_SUP = 0x4015060A |
"Hard reset not supported"
| uint32 INOS_MCMSG_CODE_INCO_DBG_INVALID_ARGUMENT = 0x4015060E |
"Invalid argument passed"
| uint32 INOS_MCMSG_CODE_INCO_DBG_INVALID_COOKIE = 0x40150614 |
"Unknown cookie received"
| uint32 INOS_MCMSG_CODE_INCO_DBG_NO_LOAD_DEVICE = 0x4015060B |
"No load device found to handle request"
| uint32 INOS_MCMSG_CODE_INCO_DBG_SOFT_RESET_NOT_ALWD = 0x4015060C |
"Soft reset not allowed"
| uint32 INOS_MCMSG_CODE_INCO_DBG_TSK_BKPT_NOT_VALID = 0x40150604 |
"Task breakpoint not valid"
| uint32 INOS_MCMSG_CODE_INCO_DBG_TSK_BKPT_SET = 0x40150605 |
"Task breakpoint already set"
| uint32 INOS_MCMSG_CODE_INCO_DBG_TSK_DATA_LENGTH = 0x40150606 |
"Task data wrong length for requested data"
| uint32 INOS_MCMSG_CODE_INCO_DBG_TSK_DATA_PUT_NA = 0x40150608 |
"Task data put not allowed"
| uint32 INOS_MCMSG_CODE_INCO_DBG_TSK_DATA_UNKNOWN = 0x40150607 |
"Task data unknown data request"
| uint32 INOS_MCMSG_CODE_INCO_DBG_TSK_ID_NOT_VALID = 0x40150601 |
"Task id not valid"
| uint32 INOS_MCMSG_CODE_INCO_DBG_TSK_NAME_NOT_VALID = 0x40150602 |
"Task name not valid"
| uint32 INOS_MCMSG_CODE_INCO_DBG_TSK_NO_FLOAT = 0x40150603 |
"Task has no floating point"
| uint32 INOS_MCMSG_CODE_INCO_DBG_TSK_NOT_DBG_SUSP = 0x40150611 |
"operation failed because task state is not debug suspended"
| uint32 INOS_MCMSG_CODE_INCO_DBG_WTP_CLEAR = 0x40150610 |
"Trying to clear unknown watchpoint"
| uint32 INOS_MCMSG_CODE_INCO_DBG_WTP_COREMSK_NOT_SUP = 0x40150617 |
"Watchpoint coremask not supported"
| uint32 INOS_MCMSG_CODE_INCO_DBG_WTP_INVALID_ACCESS = 0x4015061A |
"Invalid watchpoint access type given"
| uint32 INOS_MCMSG_CODE_INCO_DBG_WTP_INVALID_INDEX = 0x40150619 |
"Invalid watchpoint index given"
| uint32 INOS_MCMSG_CODE_INCO_DBG_WTP_NOT_FOUND = 0x40150618 |
"Watchpoint not found"
| uint32 INOS_MCMSG_CODE_INCO_DBG_WTP_NUMBER = 0x4015060F |
"Number of watchpoints exceeded"
| uint32 INOS_MCMSG_CODE_INCO_DBG_WTP_OVERLAPPED = 0x4015061B |
"Overlapping watchpoints are not allowed"
| uint32 INOS_MCMSG_CODE_INCO_INVALIDPATH = 0x401500F7 |
"Invalid INCO path"
| uint32 INOS_MCMSG_CODE_INCO_RPC_ARGFORMAT = 0x4015040b |
"INCO procedure error in argument formatting ('\', \", :l...)"
| uint32 INOS_MCMSG_CODE_INCO_RPC_ARGTOOLONG = 0x40150409 |
"INCO procedure argument is too long"
| uint32 INOS_MCMSG_CODE_INCO_RPC_ASYNC = 0x401504fe |
"INCO procedure execution is async. This is a 'virtual' error only used for communication between the target and the INCOServer"
| uint32 INOS_MCMSG_CODE_INCO_RPC_ASYNC_RES_FAILED = 0x40150500 |
"INCO procedure async result send failure"
| uint32 INOS_MCMSG_CODE_INCO_RPC_ASYNC_RES_PDP_CHN_FAIL = 0x40150506 |
"INCO procedure async result failed to create PDP channel"
| uint32 INOS_MCMSG_CODE_INCO_RPC_ASYNC_RES_RETRY = 0x40150501 |
"INCO procedure async result send with retries"
| uint32 INOS_MCMSG_CODE_INCO_RPC_ASYNC_RES_TIMEOUT = 0x40150503 |
"INCO procedure async result acknowledge timeout"
| uint32 INOS_MCMSG_CODE_INCO_RPC_ASYNC_RES_UDP_CHN_FAIL = 0x40150505 |
"INCO procedure async result failed to create UDP channel"
| uint32 INOS_MCMSG_CODE_INCO_RPC_ASYNC_RES_WRITE_FAIL = 0x40150507 |
"INCO procedure async result write failure"
| uint32 INOS_MCMSG_CODE_INCO_RPC_ASYNC_RES_WRONG_ACK_NUM = 0x40150502 |
"INCO procedure async result wrong acknowledge number"
| uint32 INOS_MCMSG_CODE_INCO_RPC_ASYNC_RES_WRONG_ACK_SIZE = 0x40150504 |
"INCO procedure async result wrong acknowledge size"
| uint32 INOS_MCMSG_CODE_INCO_RPC_BASE = 0x40150400 |
"Generic INCO procedure error"
| uint32 INOS_MCMSG_CODE_INCO_RPC_DUPLICATE_MSGID = 0x40150509 |
"INCO procedure already pending for given message id"
| uint32 INOS_MCMSG_CODE_INCO_RPC_INPROGRESS = 0x40150406 |
"INCO procedure'Virtual error': this value will be set as a task error (see CINOSTask::SetError) during the time that a procedure is called by INCO"
| uint32 INOS_MCMSG_CODE_INCO_RPC_KEYLEVEL = 0x40150417 |
"INCO user access level insufficient"
| uint32 INOS_MCMSG_CODE_INCO_RPC_MULTIDISP = 0x4015040a |
"INCO procedure failure with multidispatch: at least one callprocedure failed. Note: currently only used by INIX on PC side"
| uint32 INOS_MCMSG_CODE_INCO_RPC_NOFLOAT = 0x40150407 |
"INCO procedure doesn't support return type float"
| uint32 INOS_MCMSG_CODE_INCO_RPC_NOTARPC = 0x40150402 |
"INCO item is not a procedure object"
| uint32 INOS_MCMSG_CODE_INCO_RPC_NOTEXEC = 0x40150405 |
"INCO procedure is not executable at the moment"
| uint32 INOS_MCMSG_CODE_INCO_RPC_NOTFOUND = 0x40150401 |
"INCO procedure not found"
| uint32 INOS_MCMSG_CODE_INCO_RPC_NUMBERPARAM = 0x40150403 |
"INCO procedure wrong number of parameters"
| uint32 INOS_MCMSG_CODE_INCO_RPC_RESULT_TOO_LARGE = 0x40150418 |
"INCO procedure async result length exceeds payload buffer"
| uint32 INOS_MCMSG_CODE_INCO_RPC_TICKET_OVERFLOW = 0x40150508 |
"INCO procedure ticket overflow. This could possibly invalidate long-lasting CallProcedures on PC side."
| uint32 INOS_MCMSG_CODE_INCO_RPC_UNKNOWN = 0x401504ff |
"INCO procedure unknown function call"
| uint32 INOS_MCMSG_CODE_INCO_RPC_UNKNOWN_MSGID = 0x4015050A |
"INCO procedure unknown message id"
| uint32 INOS_MCMSG_CODE_INCO_RPC_USERERR = 0x40150480 |
"INCO procedure returned a user specific error"
| uint32 INOS_MCMSG_CODE_INCO_RPC_VALUERANGE = 0x40150408 |
"INCO procedure value out of range"
| uint32 INOS_MCMSG_CODE_INCO_RPC_WRONGPARAM = 0x40150404 |
"INCO procedure wrong parameter type"
| uint32 INOS_MCMSG_CODE_INCO_UNKNOWNFRAME = 0x401500FF |
"Target doesn't support this INCO frame type"
| uint32 INOS_MCMSG_CODE_INCO_VAR_ARRAYINDEX = 0x40150206 |
"Variable array index out of bound"
| uint32 INOS_MCMSG_CODE_INCO_VAR_ASYNCRESLOST = 0x4015020e |
"Asynchronous variable getter did not return a result, or result was already purged from ring buffer. Note: currently only used by INIX on PC side"
| uint32 INOS_MCMSG_CODE_INCO_VAR_BASE = 0x40150200 |
"Generic INCO variable error"
| uint32 INOS_MCMSG_CODE_INCO_VAR_BITNUMBER = 0x40150209 |
"Variable bit number not allowed"
| uint32 INOS_MCMSG_CODE_INCO_VAR_BUFSIZE = 0x4015020a |
"Variable buffer to small. Note: currently only used on PC side"
| uint32 INOS_MCMSG_CODE_INCO_VAR_EMENOTALLOWED = 0x4015020d |
"Variable read/write not allowed for emergency incodispatcher"
| uint32 INOS_MCMSG_CODE_INCO_VAR_KEYLEVEL = 0x40150207 |
"Variable keylevel not enough"
| uint32 INOS_MCMSG_CODE_INCO_VAR_MAXIMUM = 0x40150204 |
"Variable maximum value reached"
| uint32 INOS_MCMSG_CODE_INCO_VAR_MINIMUM = 0x40150203 |
"Variable minimum value reached"
| uint32 INOS_MCMSG_CODE_INCO_VAR_MULTIDISP = 0x4015020b |
"Multidispatch failed. Note: currently only used by INIX on PC side"
| uint32 INOS_MCMSG_CODE_INCO_VAR_NAMELENGTH = 0x40150213 |
"McFrame to ClassicFrame conversion: the variable name length is too long (i.e. does not fit into the maximum possible frame length)"
| uint32 INOS_MCMSG_CODE_INCO_VAR_NOTFOUND = 0x40150201 |
"Variable not found"
| uint32 INOS_MCMSG_CODE_INCO_VAR_NOTNUMBER = 0x40150212 |
"GetVariable was called to read a number, but the variable is not of type number"
| uint32 INOS_MCMSG_CODE_INCO_VAR_NOTSTRING = 0x40150211 |
"GetVariable was called to read a string, but the variable is not of type string"
| uint32 INOS_MCMSG_CODE_INCO_VAR_PROPNOTFOUND = 0x40150208 |
"Variable property not found"
| uint32 INOS_MCMSG_CODE_INCO_VAR_PUTBUFSIZE = 0x40150214 |
"McFrame to ClassicFrame conversion: the communication buffer is too small to put the variable. Variable name/path and or variable value exceeds maximum length"
| uint32 INOS_MCMSG_CODE_INCO_VAR_PUTGETEX_NOT_SUPPORTED = 0x40150217 |
"Put/GetVariableEx not supported"
| uint32 INOS_MCMSG_CODE_INCO_VAR_PUTGETEX_SIZE_MISMATCH = 0x40150216 |
"Put/GetVariableEx size mismatch detected"
| uint32 INOS_MCMSG_CODE_INCO_VAR_PUTGETEX_TYPE_MISMATCH = 0x40150215 |
"Put/GetVariableEx type mismatch detected"
| uint32 INOS_MCMSG_CODE_INCO_VAR_PUTGETEX_VALUE_TOO_BIG = 0x40150218 |
"Value too big to be represented in a double, use Get/PutVariableEx instead"
| uint32 INOS_MCMSG_CODE_INCO_VAR_READONLY = 0x40150202 |
"Variable is read only"
| uint32 INOS_MCMSG_CODE_INCO_VAR_STRLENGTH = 0x40150205 |
"Variable string length error"
| uint32 INOS_MCMSG_CODE_INCO_VAR_TRIGSYNTAX = 0x4015020f |
"The trigger command has wrong syntax. Note: currently only used by INIX on PC side"
| uint32 INOS_MCMSG_CODE_INCO_VAR_TRIGTWICE = 0x4015020c |
"A trigger with the same action and of the same type is already registered. Note: currently only used by INIX on PC side"
| uint32 INOS_MCMSG_CODE_INCO_VAR_TYPEUNSUPP = 0x40150210 |
"The type is unsupported. Depending whether a GetVariable or PutVariable was performed, this means that either INOS or the inco_32.dll should be updated"
| uint32 INOS_MCMSG_CODE_INCO_VAR_UNKNOWN = 0x401502ff |
"Target doesn't support this 'variable' frame sub type"
| uint32 INOS_MCMSG_CODE_INCO_VAR_USERERR = 0x40150280 |
"Variable user errors"
| uint32 INOS_MCMSG_CODE_INCO_VAR_VARASYNC = 0x401502fe |
"Variable access is async. This is a 'virtual' error only used for communication between the target and the INCOServer"
| uint32 INOS_MCMSG_CODE_LUA_BAD_STACK_FRAME = 0x40040011 |
"Lua debug, invalid stack frame"
| uint32 INOS_MCMSG_CODE_LUA_BAD_VAL_TYPE = 0x4004000F |
"Lua debug value-type"
| uint32 INOS_MCMSG_CODE_LUA_BAD_VAR_NAME = 0x40040010 |
"Lua debug, invalid variable name"
| uint32 INOS_MCMSG_CODE_LUA_CALL_ERROR = 0x40040003 |
"Lua function call error"
| uint32 INOS_MCMSG_CODE_LUA_CHUNK_TYPE = 0x40040013 |
"Lua RunChunk called with param wrong type"
| uint32 INOS_MCMSG_CODE_LUA_COMPILE_ERROR = 0x40040002 |
"Lua compile error"
| uint32 INOS_MCMSG_CODE_LUA_CONFLICTING_PATH = 0x40040004 |
"Conflicting path error"
| uint32 INOS_MCMSG_CODE_LUA_EMPTY_TASK_NAME = 0x4004000C |
"Lua task name empty"
| uint32 INOS_MCMSG_CODE_LUA_ERR_ERROR = 0x40040001 |
"Lua error handling error"
| uint32 INOS_MCMSG_CODE_LUA_ERR_NUMBER_OF_PARAMETERS = 0x40040017 |
"Invalid number of parameters"
| uint32 INOS_MCMSG_CODE_LUA_ERR_RETURN_INCOMPLETE = 0x40040016 |
"Lua script returned incomplete McResult"
| uint32 INOS_MCMSG_CODE_LUA_ERR_RETURN_NOVALUES = 0x40040015 |
"Lua script returned too many values"
| uint32 INOS_MCMSG_CODE_LUA_GC_ERROR = 0x40040025 |
"Lua garbage collection error"
| uint32 INOS_MCMSG_CODE_LUA_MAX_PARAM_TABLE_DEPTH = 0x40040020 |
"Maximal depth of table structure for message/result param exceeded."
| uint32 INOS_MCMSG_CODE_LUA_MEMORY_ERROR = 0x4004001B |
"Lua memory error"
| uint32 INOS_MCMSG_CODE_LUA_MISSING_EVENT_FOR_TRIGGER = 0x4004001F |
"Event for trigger missing after completed call."
| uint32 INOS_MCMSG_CODE_LUA_MUTEX_TASK_ERROR = 0x40040007 |
"Wrong Lua task tried to release mutex"
| uint32 INOS_MCMSG_CODE_LUA_NON_EXISTING_CMD = 0x40040018 |
"Command does not exist anymore"
| uint32 INOS_MCMSG_CODE_LUA_NON_EXISTING_MOD = 0x40040019 |
"Module does not exist anymore"
| uint32 INOS_MCMSG_CODE_LUA_PARAM_TABLE_KEY_TYPE = 0x40040021 |
"Param table keys must be of type string or number."
| uint32 INOS_MCMSG_CODE_LUA_PARAM_TO_LUA_VALUE_TYPE = 0x40040023 |
"McRobot param to Lua value conversion failed."
| uint32 INOS_MCMSG_CODE_LUA_PARAM_TO_UD_FAILED = 0x40040024 |
"McRobot param to Lua userdata conversion failed."
| uint32 INOS_MCMSG_CODE_LUA_RESERVED = 0x4004001C |
"Depracated error, use me for next error definition"
| uint32 INOS_MCMSG_CODE_LUA_RUNTIME_ERROR = 0x40040000 |
"Lua runtime error"
| uint32 INOS_MCMSG_CODE_LUA_SCRIPT_NOT_FOUND = 0x40040008 |
"Lua script not found"
| uint32 INOS_MCMSG_CODE_LUA_SET_VAR_BAD_PATH = 0x4004000E |
"Lua set variable on invalid path"
| uint32 INOS_MCMSG_CODE_LUA_SET_VAR_TYPE = 0x4004000D |
"Lua set variable not supported for this type"
| uint32 INOS_MCMSG_CODE_LUA_SHUTDOWN_WITH_TASKS = 0x4004001E |
"Shutdown of Lua with active tasks is not possible"
| uint32 INOS_MCMSG_CODE_LUA_TASK_ALREADY_EXISTS = 0x4004001A |
"Lua task already exists"
| uint32 INOS_MCMSG_CODE_LUA_TASK_BUSY = 0x40040009 |
"Lua task is busy"
| uint32 INOS_MCMSG_CODE_LUA_TASK_NOT_FOUND = 0x4004000B |
"Lua task is not found"
| uint32 INOS_MCMSG_CODE_LUA_TASK_NOT_LOADED = 0x4004000A |
"Lua task is not in state loaded"
| uint32 INOS_MCMSG_CODE_LUA_TOP_REGISTER = 0x40040006 |
"Top module registration error"
| uint32 INOS_MCMSG_CODE_LUA_UD_TO_PARAM_FAILED = 0x40040022 |
"Lua userdata to McRobot param conversion failed."
| uint32 INOS_MCMSG_CODE_LUA_UNEXPECTED_INTERNAL_ERROR = 0x4004001D |
"Unexpected error while accessing Lua state from internal function"
| uint32 INOS_MCMSG_CODE_LUA_UNKNOWN_MODULE = 0x40040005 |
"Module not defined"
| uint32 INOS_MCMSG_CODE_LUA_UNKNOWN_SEMAPHORE_ERROR = 0x40040014 |
"Unknown Lua semaphore"
| uint32 INOS_MCMSG_CODE_LUA_VALUE_TO_PARAM_TYPE = 0x40040012 |
"Lua conversion to McRobot praram error: Unsupported type"
| uint32 INOS_MCMSG_CODE_MESSAGE_INVALID_INDEX = 0x40050000 |
"Invalid message index"
| uint32 INOS_MCMSG_CODE_MESSAGE_UNKNOWN_ID = 0x40050001 |
"Unknown message id"
| uint32 INOS_MCMSG_CODE_MESSAGE_WRONG_FLAG = 0x40050002 |
"Wrong flag given to ack message"
| uint32 INOS_MCMSG_CODE_MODULE_CONTAINER_FAILED = 0x4002001C |
"Container operation failed"
| uint32 INOS_MCMSG_CODE_MODULE_CONTAINER_REJECTED = 0x4002001B |
"Container operation rejected"
| uint32 INOS_MCMSG_CODE_MODULE_DUPLICATE_DATA = 0x40020022 |
"Duplicate data instance name"
| uint32 INOS_MCMSG_CODE_MODULE_DUPLICATE_MODULE = 0x40020023 |
"Duplicate module name"
| uint32 INOS_MCMSG_CODE_MODULE_EMERGENCY_STOP = 0x40020005 |
"Emergency stop pressed"
| uint32 INOS_MCMSG_CODE_MODULE_INVAL_RES_STATE = 0x40020013 |
"Invalid resource state"
| uint32 INOS_MCMSG_CODE_MODULE_LINK_DOWN = 0x40020014 |
"Link down detected"
| uint32 INOS_MCMSG_CODE_MODULE_NO_COORD = 0x40020001 |
"No coordinator available"
| uint32 INOS_MCMSG_CODE_MODULE_NO_CRON = 0x4002000C |
"No cron support available"
| uint32 INOS_MCMSG_CODE_MODULE_NO_DATA = 0x40020016 |
"No data available"
| uint32 INOS_MCMSG_CODE_MODULE_NO_FIELDBUS = 0x40020012 |
"No fieldbus available"
| uint32 INOS_MCMSG_CODE_MODULE_NO_JOB = 0x4002001A |
"No job available"
| uint32 INOS_MCMSG_CODE_MODULE_NO_LUA = 0x40020017 |
"No lua interpreter available"
| uint32 INOS_MCMSG_CODE_MODULE_NO_MODULE = 0x40020015 |
"No module available"
| uint32 INOS_MCMSG_CODE_MODULE_NO_SCRIPT = 0x40020019 |
"No script available"
| uint32 INOS_MCMSG_CODE_MODULE_NO_VALID_BACKUP = 0x40020011 |
"No valid backup found"
| uint32 INOS_MCMSG_CODE_MODULE_OVLD_NOT_SUPPORTED = 0x40020025 |
"Overloaded commands are not supported, remove 'Ovld' from your module params"
| uint32 INOS_MCMSG_CODE_MODULE_REGEX_INVALID = 0x40020028 |
"Invalid regex string given"
| uint32 INOS_MCMSG_CODE_MODULE_REGISTER_HOOK_NOT_SUP = 0x40020027 |
"RegisterHook not supported for this type of resource"
| uint32 INOS_MCMSG_CODE_MODULE_RES_ALREADY_EXISTS = 0x4002001D |
"Resource already exists"
| uint32 INOS_MCMSG_CODE_MODULE_RES_GETIO_FAILED = 0x4002001F |
"GetIO failed. Either the resource type is unsupported or the image object is not available"
| uint32 INOS_MCMSG_CODE_MODULE_SAFE_TORQUE_OFF = 0x4002001E |
"Safe torque off (STO) detected"
| uint32 INOS_MCMSG_CODE_MODULE_SAFETY_CONFIG_UPDATE = 0x40020024 |
"Switched off due to safety config update"
| uint32 INOS_MCMSG_CODE_MODULE_SCRIPT_CHANGED = 0x4002000F |
"Script changed since pause"
| uint32 INOS_MCMSG_CODE_MODULE_SECOND_JOB = 0x40020018 |
"Can not run a second job"
| uint32 INOS_MCMSG_CODE_MODULE_SETITEM_SUBMODULE = 0x40020026 |
"SetItem on item of sub-module not allowed. Call SetItem command of the sub-module."
| uint32 INOS_MCMSG_CODE_MODULE_STEP = 0x4002000B |
"Step"
| uint32 INOS_MCMSG_CODE_MODULE_UNDEFINED_RES = 0x40020006 |
"Undefined resource"
| uint32 INOS_MCMSG_CODE_MODULE_UNKNOWN_CMD_ID = 0x40020010 |
"Unknown command id"
| uint32 INOS_MCMSG_CODE_MODULE_UNKNOWN_CRON = 0x4002000D |
"Unknown cron job"
| uint32 INOS_MCMSG_CODE_MODULE_UNKNOWN_DATA = 0x40020020 |
"Unknown data instance name"
| uint32 INOS_MCMSG_CODE_MODULE_UNKNOWN_JOB = 0x40020003 |
"Unknown job"
| uint32 INOS_MCMSG_CODE_MODULE_UNKNOWN_MODULE = 0x40020021 |
"Unknown module name"
| uint32 INOS_MCMSG_CODE_MODULE_UNKNOWN_OUT_RES = 0x4002000A |
"Unknown output resource"
| uint32 INOS_MCMSG_CODE_MODULE_UNKNOWN_RES = 0x40020007 |
"Unknown resource"
| uint32 INOS_MCMSG_CODE_MODULE_UNKNOWN_RES_CLR = 0x40020009 |
"Unknown resource 'Clear' command"
| uint32 INOS_MCMSG_CODE_MODULE_UNKNOWN_RES_SET = 0x40020008 |
"Unknown resource 'Set' command"
| uint32 INOS_MCMSG_CODE_MODULE_UNKNOWN_SCRIPT = 0x40020002 |
"Unknown script"
| uint32 INOS_MCMSG_CODE_MODULE_UNKNOWN_STREAM = 0x40020004 |
"Unknown stream"
| uint32 INOS_MCMSG_CODE_MODULE_WAITBIT_TIMEOUT = 0x4002000E |
"WaitBit timeout"
| uint32 INOS_MCMSG_CODE_NVRAM_DEVICE_NOT_WORKING = 0x4011000F |
"NvRam device is not working, reboot is required"
| uint32 INOS_MCMSG_CODE_NVRAM_GROUP_CONFLICT = 0x40110005 |
"NvRam group naming conflict"
| uint32 INOS_MCMSG_CODE_NVRAM_GROUP_CREATED = 0x40110004 |
"NvRam group created"
| uint32 INOS_MCMSG_CODE_NVRAM_ID_INVALID = 0x4011000D |
"Invalid NvRam id given"
| uint32 INOS_MCMSG_CODE_NVRAM_INITIALISED = 0x40110001 |
"NvRam initialised"
| uint32 INOS_MCMSG_CODE_NVRAM_LONG_STRING_CUTTED = 0x4011000E |
"NvRam long string cutted to normal string, reset NvRam to solve"
| uint32 INOS_MCMSG_CODE_NVRAM_MAX_WARNING = 0x40110002 |
"Max. number of NvRam warnings reached"
| uint32 INOS_MCMSG_CODE_NVRAM_NO_NVRAM = 0x40110003 |
"No NvRam available"
| uint32 INOS_MCMSG_CODE_NVRAM_UNKNOWN_TYPE = 0x4011000C |
"Unknown NvRam value type detected"
| uint32 INOS_MCMSG_CODE_NVRAM_VALUE_CONFLICT = 0x40110007 |
"NvRam value naming conflict"
| uint32 INOS_MCMSG_CODE_NVRAM_VALUE_CREATED = 0x40110006 |
"NvRam value created"
| uint32 INOS_MCMSG_CODE_NVRAM_VALUE_INVALID = 0x40110008 |
"NvRam value invalid"
| uint32 INOS_MCMSG_CODE_NVRAM_VALUE_NO_HND = 0x40110009 |
"No NvRam handler found"
| uint32 INOS_MCMSG_CODE_NVRAM_VALUE_NOT_FOUND = 0x4011000A |
"NvRam value not found"
| uint32 INOS_MCMSG_CODE_NVRAM_WRONG_TYPE = 0x4011000B |
"Wrong NvRam value type detected"
| uint32 INOS_MCMSG_CODE_ROBOT_24V_LOGIC_LOW = 0x40030322 |
"24V logic low"
| uint32 INOS_MCMSG_CODE_ROBOT_ABS_ENCODER_HAS_ERRORS = 0x40030326 |
"Absolute encoder has errors"
| uint32 INOS_MCMSG_CODE_ROBOT_ABS_ENCODER_HAS_WARNINGS = 0x4003071C |
"Absolute encoder has warnings"
| uint32 INOS_MCMSG_CODE_ROBOT_ABSENC_READ_ERRORS = 0x40030053 |
"Error reads on absolute encoder, please check the connection"
| uint32 INOS_MCMSG_CODE_ROBOT_ABSENC_READ_FAILED = 0x40030052 |
"Failed to read absolute encoder"
| uint32 INOS_MCMSG_CODE_ROBOT_ABSENC_READ_NO_OK = 0x40030054 |
"No ok reads on absolute encoder, please check the configuration"
| uint32 INOS_MCMSG_CODE_ROBOT_ABSENC_TYPE_READ_FAILED = 0x40030050 |
"Failed to read absolute encoder type"
| uint32 INOS_MCMSG_CODE_ROBOT_ABSENC_TYPE_UNKNOWN = 0x40030051 |
"Unknown absolute encoder type detected"
| uint32 INOS_MCMSG_CODE_ROBOT_ACTIVATE = 0x4003030D |
"Activation error"
| uint32 INOS_MCMSG_CODE_ROBOT_AXIS_BUSY = 0x40030005 |
"Invalid 'move in move'"
| uint32 INOS_MCMSG_CODE_ROBOT_AXIS_CORE_MISMATCH = 0x4003010C |
"Axis command called from wrong core"
| uint32 INOS_MCMSG_CODE_ROBOT_AXIS_ERROR = 0x40030017 |
"Axis on error"
| uint32 INOS_MCMSG_CODE_ROBOT_AXIS_WRN_CORE_MISMATCH = 0x40030505 |
"Axis command called from wrong core"
| uint32 INOS_MCMSG_CODE_ROBOT_BASE = 0x40030000 |
"Base message code"
| uint32 INOS_MCMSG_CODE_ROBOT_BORDER_MANDATORY = 0x4003001F |
"Border support mandatory for this Init type"
| uint32 INOS_MCMSG_CODE_ROBOT_BORDERLIMIT_SUPP = 0x40030042 |
"BorderLimit property must be supported by this axis type for 'init to border'"
| uint32 INOS_MCMSG_CODE_ROBOT_BORDERLIMIT_VALUE = 0x40030043 |
"BorderLimit must be set to a useful value (e.g. in dt2) for this axis for 'init to border'"
| uint32 INOS_MCMSG_CODE_ROBOT_BRAKE_I2T = 0x40030321 |
"Ballast I2t > 100%"
| uint32 INOS_MCMSG_CODE_ROBOT_BRAKE_I2T_WRN = 0x4003071A |
"Ballast I2t > 100%"
| uint32 INOS_MCMSG_CODE_ROBOT_CALC_EVENT_FAILED = 0x40030014 |
"Calc event time failed"
| uint32 INOS_MCMSG_CODE_ROBOT_CALC_MOVING_TIME = 0x40030007 |
"Calc moving time failed"
| uint32 INOS_MCMSG_CODE_ROBOT_CALC_TRG_FAILED = 0x40030015 |
"Calc trigger point failed"
| uint32 INOS_MCMSG_CODE_ROBOT_CALIB_AXIS_CALIB = 0x40030035 |
"Calib not allowed, pos channel calibration enabled"
| uint32 INOS_MCMSG_CODE_ROBOT_CALIB_BUSY = 0x40030036 |
"Calib not allowed, axis busy"
| uint32 INOS_MCMSG_CODE_ROBOT_CALIB_NOT_ALLOWED = 0x40030037 |
"Calib of coupled axis not allowed"
| uint32 INOS_MCMSG_CODE_ROBOT_CALIB_RANGE_TOO_SMALL = 0x4003003B |
"Calib range too small"
| uint32 INOS_MCMSG_CODE_ROBOT_CMD_FAILED = 0x40030101 |
"Axis command failed"
| uint32 INOS_MCMSG_CODE_ROBOT_CMD_IGNORED = 0x40030500 |
"Axis command ignored"
| uint32 INOS_MCMSG_CODE_ROBOT_CMD_REJECTED = 0x40030100 |
"Axis command rejected"
| uint32 INOS_MCMSG_CODE_ROBOT_CMD_RESULT_ON_STACK = 0x4003005B |
"Result of McRobot command can't be on stack, use a member variable instead"
| uint32 INOS_MCMSG_CODE_ROBOT_COM_FAILED = 0x40030106 |
"Communication to foreign controller failed"
| uint32 INOS_MCMSG_CODE_ROBOT_CONCURRENT_PREPAREPATH = 0x40030049 |
"Concurrent PreparePath commands are not allowed"
| uint32 INOS_MCMSG_CODE_ROBOT_CONCURRENT_RUNPATH = 0x4003004A |
"Concurrent RunPath commands are not allowed"
| uint32 INOS_MCMSG_CODE_ROBOT_CONTROLLER_TOO_FAST = 0x40030041 |
"Controller sampling rate too high"
| uint32 INOS_MCMSG_CODE_ROBOT_CPD_CORR = 0x40030105 |
"Max. allowed coupling correction exceeded"
| uint32 INOS_MCMSG_CODE_ROBOT_CPD_CORR_IGNORED = 0x40030501 |
"Coupling correction ignored"
| uint32 INOS_MCMSG_CODE_ROBOT_CPD_DELTA = 0x40030104 |
"Max. allowed coupling delta reached"
| uint32 INOS_MCMSG_CODE_ROBOT_CPD_ERROR = 0x40030103 |
"Coupled axis on error"
| uint32 INOS_MCMSG_CODE_ROBOT_CPD_WARNING = 0x40030503 |
"Coupled axis has warnings"
| uint32 INOS_MCMSG_CODE_ROBOT_CTRL_TEMP = 0x40030314 |
"External controller max. temperature exceeded"
| uint32 INOS_MCMSG_CODE_ROBOT_CTRL_TEMP_HIGH = 0x40030714 |
"Controller temperature high"
| uint32 INOS_MCMSG_CODE_ROBOT_CYCLETIME_INVALID = 0x4003002A |
"Cycletime of axis doesn't match LinkSamplingRate in controller"
| uint32 INOS_MCMSG_CODE_ROBOT_DISCH_FAILED = 0x40030718 |
"Discharge failed"
| uint32 INOS_MCMSG_CODE_ROBOT_DIST_CODED_DATA_MISSING = 0x4003004F |
"Distance coded configuration data missing"
| uint32 INOS_MCMSG_CODE_ROBOT_DIST_CODED_IMPL_MISSING = 0x4003004E |
"Distance coded implementation missing (method CINOSMcRobot::GetDistanceCodedPosition not overwritten)"
| uint32 INOS_MCMSG_CODE_ROBOT_EMG_STOPPED = 0x40030504 |
"Axis has been emergency stopped"
| uint32 INOS_MCMSG_CODE_ROBOT_ENABLE_MISSING = 0x40030303 |
"Enable missing"
| uint32 INOS_MCMSG_CODE_ROBOT_EVENT_NOT_SUP = 0x4003002D |
"Event type not supported"
| uint32 INOS_MCMSG_CODE_ROBOT_EXT_EN = 0x4003031E |
"External enable missing"
| uint32 INOS_MCMSG_CODE_ROBOT_EXT_STOP = 0x40030310 |
"External controller stop"
| uint32 INOS_MCMSG_CODE_ROBOT_EXTERN = 0x4003030E |
"External controller error"
| uint32 INOS_MCMSG_CODE_ROBOT_EXTERN_WRN = 0x4003070E |
"External controller warning"
| uint32 INOS_MCMSG_CODE_ROBOT_FCTRL_BREAK_FAILED = 0x40030812 |
"Force command 'Break' failed, no collapse detected"
| uint32 INOS_MCMSG_CODE_ROBOT_FCTRL_COLLAPSE_AS_ERROR_NOT_ALLOWED = 0x40030811 |
"Force command 'Break' does not allow collapse as error"
| uint32 INOS_MCMSG_CODE_ROBOT_FCTRL_COLLAPSED = 0x4003080E |
"Force control collapse detected"
| uint32 INOS_MCMSG_CODE_ROBOT_FCTRL_CONCURRENT = 0x40030801 |
"Concurrent force commands are not allowed"
| uint32 INOS_MCMSG_CODE_ROBOT_FCTRL_ENABLED_COLLAPSE_DETECTION_REQUIRED = 0x40030810 |
"Force command 'Break' requires enabled collapse detection"
| uint32 INOS_MCMSG_CODE_ROBOT_FCTRL_NOT_AVAILABLE = 0x40030800 |
"Force controller not available"
| uint32 INOS_MCMSG_CODE_ROBOT_FCTRL_NOT_SUPPORTED = 0x4003080D |
"Force control not supported by external controller"
| uint32 INOS_MCMSG_CODE_ROBOT_FCTRL_STAB_TIMEOUT = 0x40030803 |
"Timeout stabilizing force control"
| uint32 INOS_MCMSG_CODE_ROBOT_FCTRL_TOUCH_DOWN_ERR = 0x40030804 |
"Searching touch down failed"
| uint32 INOS_MCMSG_CODE_ROBOT_FCTRL_UNKNOWN_PARAM = 0x40030805 |
"Unknown param set requested"
| uint32 INOS_MCMSG_CODE_ROBOT_FCTRL_WRONG_ASTATE = 0x40030802 |
"Force command not allowed, axis in wrong state"
| uint32 INOS_MCMSG_CODE_ROBOT_FCTRL_WRONG_FSTATE_ACT = 0x40030806 |
"Force command 'Activate' not allowed, controller in wrong state"
| uint32 INOS_MCMSG_CODE_ROBOT_FCTRL_WRONG_FSTATE_APP = 0x40030807 |
"Force command 'Approach' not allowed, controller in wrong state"
| uint32 INOS_MCMSG_CODE_ROBOT_FCTRL_WRONG_FSTATE_BRK = 0x4003080F |
"Force command 'Break' not allowed, controller in wrong state"
| uint32 INOS_MCMSG_CODE_ROBOT_FCTRL_WRONG_FSTATE_DEP = 0x40030808 |
"Force command 'Depart' not allowed, controller in wrong state"
| uint32 INOS_MCMSG_CODE_ROBOT_FCTRL_WRONG_FSTATE_LIM = 0x4003080B |
"Force command 'Limit' not allowed, controller in wrong state"
| uint32 INOS_MCMSG_CODE_ROBOT_FCTRL_WRONG_FSTATE_MOV = 0x40030809 |
"Force command 'Move' not allowed, controller in wrong state"
| uint32 INOS_MCMSG_CODE_ROBOT_FCTRL_WRONG_FSTATE_MOV_STOP = 0x40030814 |
"Force command 'MoveStop' not allowed, controller in wrong state"
| uint32 INOS_MCMSG_CODE_ROBOT_FCTRL_WRONG_FSTATE_PUL = 0x40030813 |
"Force command 'Pull' not allowed, controller in wrong state"
| uint32 INOS_MCMSG_CODE_ROBOT_FCTRL_WRONG_FSTATE_SEL = 0x4003080C |
"Force command 'Select' not allowed, controller in wrong state"
| uint32 INOS_MCMSG_CODE_ROBOT_FCTRL_WRONG_FSTATE_TAR = 0x4003080A |
"Force command 'Tara' not allowed, controller in wrong state"
| uint32 INOS_MCMSG_CODE_ROBOT_FIELDBUS_WATCHDOG = 0x40030320 |
"Fieldbus watchdog occurred"
| uint32 INOS_MCMSG_CODE_ROBOT_FSL_LIMIT = 0x40030701 |
"Full scale limit reached"
| uint32 INOS_MCMSG_CODE_ROBOT_GSB_ACTIVATE = 0x4003130D |
"Activation error"
| uint32 INOS_MCMSG_CODE_ROBOT_GSB_EXTERN = 0x4003130E |
"External controller error"
| uint32 INOS_MCMSG_CODE_ROBOT_GSB_NO_POS = 0x4003130C |
"No position channel available"
| uint32 INOS_MCMSG_CODE_ROBOT_GSB_OVR = 0x40031301 |
"Position channel overrun detected"
| uint32 INOS_MCMSG_CODE_ROBOT_GSB_POS_CHECK = 0x40031300 |
"Position check error"
| uint32 INOS_MCMSG_CODE_ROBOT_GSB_POS_OFFLINE = 0x4003130F |
"Position channel offline"
| uint32 INOS_MCMSG_CODE_ROBOT_GSB_RX_FIFO_OVERRUN = 0x40031310 |
"Rx fifo overrun"
| uint32 INOS_MCMSG_CODE_ROBOT_GSB_TX_FIFO_OVERRUN = 0x40031311 |
"Tx fifo overrun"
| uint32 INOS_MCMSG_CODE_ROBOT_GSB_TX_FIFO_UNDERRUN = 0x40031312 |
"Tx fifo underrun"
| uint32 INOS_MCMSG_CODE_ROBOT_HOMING_FAILED = 0x40030304 |
"CiA402 homing failed"
| uint32 INOS_MCMSG_CODE_ROBOT_I2T = 0x40030313 |
"I2T exceeded"
| uint32 INOS_MCMSG_CODE_ROBOT_I2T_HIGH = 0x40030715 |
"Motor I2t high"
| uint32 INOS_MCMSG_CODE_ROBOT_ICONT = 0x40030319 |
"I continuous exceeded"
| uint32 INOS_MCMSG_CODE_ROBOT_ICONT_ARM = 0x40030323 |
"I continuous exceeded"
| uint32 INOS_MCMSG_CODE_ROBOT_IEND = 0x4003031B |
"Imax exceeded"
| uint32 INOS_MCMSG_CODE_ROBOT_IMAX_REACHED = 0x40030712 |
"Imax reached"
| uint32 INOS_MCMSG_CODE_ROBOT_INIT_AXIS_CALIB = 0x40030031 |
"Init not allowed, pos channel calibration enabled"
| uint32 INOS_MCMSG_CODE_ROBOT_INIT_BUSY = 0x40030018 |
"Init not allowed, axis busy"
| uint32 INOS_MCMSG_CODE_ROBOT_INIT_NOT_ALLOWED = 0x40030013 |
"Init of coupled axis not allowed"
| uint32 INOS_MCMSG_CODE_ROBOT_INT_LIMIT = 0x40030700 |
"Integrator limit reached"
| uint32 INOS_MCMSG_CODE_ROBOT_INVALID_END_POINT = 0x40030016 |
"Invalid end point"
| uint32 INOS_MCMSG_CODE_ROBOT_INVALID_JOY_DELTA = 0x4003001C |
"Invalid joystick delta"
| uint32 INOS_MCMSG_CODE_ROBOT_INVALID_LINEAR_MOVE = 0x40030028 |
"Invalid linear move"
| uint32 INOS_MCMSG_CODE_ROBOT_INVALID_POS = 0x40030004 |
"Invalid axis position"
| uint32 INOS_MCMSG_CODE_ROBOT_INVALID_START_POS = 0x40030032 |
"Invalid starting position"
| uint32 INOS_MCMSG_CODE_ROBOT_INVALID_SYNCPOINT = 0x40030029 |
"Invalid sync point"
| uint32 INOS_MCMSG_CODE_ROBOT_IOFFS = 0x4003031A |
"I offset or autocommutation failure"
| uint32 INOS_MCMSG_CODE_ROBOT_JOYSTICK_BUSY = 0x4003001A |
"Joystick not allowed, axis busy"
| uint32 INOS_MCMSG_CODE_ROBOT_JOYSTICK_DISABLING = 0x4003004D |
"Axis is already disabling joystick mode (axis is stopping right now)"
| uint32 INOS_MCMSG_CODE_ROBOT_LIMIT = 0x40030025 |
"Limit switch reached"
| uint32 INOS_MCMSG_CODE_ROBOT_LIMIT_NEG = 0x40030027 |
"Negative limit switch reached"
| uint32 INOS_MCMSG_CODE_ROBOT_LIMIT_POS = 0x40030026 |
"Positive limit switch reached"
| uint32 INOS_MCMSG_CODE_ROBOT_MAPPED_POS_OUT_OF_RANGE = 0x40030040 |
"Mapped position out of range"
| uint32 INOS_MCMSG_CODE_ROBOT_MAPPING_MISMATCH = 0x4003003F |
"Mapping mismatch detected"
| uint32 INOS_MCMSG_CODE_ROBOT_MASTER_FIELDBUS_WATCHDOG = 0x40030306 |
"GinLink master detected a fieldbus watchdog"
| uint32 INOS_MCMSG_CODE_ROBOT_MIM_DEC = 0x40030600 |
"Move in move during deceleration"
| uint32 INOS_MCMSG_CODE_ROBOT_MIM_POS_RANGE = 0x40030202 |
"Move in move position out of range"
| uint32 INOS_MCMSG_CODE_ROBOT_MISMATCH_BUSID = 0x40030009 |
"BusId mismatch"
| uint32 INOS_MCMSG_CODE_ROBOT_MISMATCH_COREID = 0x40030055 |
"Module and axes running on different cores"
| uint32 INOS_MCMSG_CODE_ROBOT_MISMATCH_CYCLENBR = 0x4003000A |
"Cyclenumber mismatch"
| uint32 INOS_MCMSG_CODE_ROBOT_MISMATCH_CYCLETIM = 0x4003000B |
"Cycletime mismatch"
| uint32 INOS_MCMSG_CODE_ROBOT_MISSING_PARAM = 0x4003002C |
"Missing param set"
| uint32 INOS_MCMSG_CODE_ROBOT_MOT_TEMP_HIGH = 0x40030716 |
"Motor temperature high"
| uint32 INOS_MCMSG_CODE_ROBOT_MOTCFG_REV_TO_HIGH = 0x40030328 |
"MotorConfig version too new for this system, please update system"
| uint32 INOS_MCMSG_CODE_ROBOT_MOTOR_CONFIG = 0x4003031F |
"Motor configuration missing or reset necessary"
| uint32 INOS_MCMSG_CODE_ROBOT_MOTOR_SHORT = 0x40030316 |
"Motor short circuit"
| uint32 INOS_MCMSG_CODE_ROBOT_MOTOR_TEMP = 0x40030315 |
"Motor max. temperature exceeded"
| uint32 INOS_MCMSG_CODE_ROBOT_MOTORCONFIG_MISSING = 0x4003005D |
"Axis motor config (cpf) missing, no config file given and flash contains no valid config"
| uint32 INOS_MCMSG_CODE_ROBOT_MOTORCONFIG_NOT_FOUND = 0x4003005C |
"Axis motor config (cpf) not found"
| uint32 INOS_MCMSG_CODE_ROBOT_MOTORCONFIG_NOT_UNIQUE = 0x4003005E |
"Axis motor config (cpf) is not unique, multiple axis uses this config and this is not allowed"
| uint32 INOS_MCMSG_CODE_ROBOT_MOVE_BUSY = 0x40030019 |
"Move not allowed, axis busy"
| uint32 INOS_MCMSG_CODE_ROBOT_MOVE_NOT_IN_CACHE = 0x40030205 |
"Trajectory was not in cache as expected"
| uint32 INOS_MCMSG_CODE_ROBOT_MOVE_OFF = 0x40030033 |
"Move not allowed, axis off"
| uint32 INOS_MCMSG_CODE_ROBOT_NO_JOYSTICK = 0x4003001B |
"Axis not in joystick mode"
| uint32 INOS_MCMSG_CODE_ROBOT_NO_POS = 0x4003030C |
"No position channel available"
| uint32 INOS_MCMSG_CODE_ROBOT_NO_SOFTLIMITS = 0x4003003A |
"Calib not allowed without soft limits"
| uint32 INOS_MCMSG_CODE_ROBOT_NO_TRG_SUPPORT = 0x40030044 |
"Trigger not supported for this command"
| uint32 INOS_MCMSG_CODE_ROBOT_NO_WHEEL = 0x4003002F |
"Axis not in wheel mode"
| uint32 INOS_MCMSG_CODE_ROBOT_NOT_YET_IMPL = 0x4003001D |
"Init type not yet implemented"
| uint32 INOS_MCMSG_CODE_ROBOT_NOTHING_TO_CALIB = 0x40030034 |
"Nothing to calib"
| uint32 INOS_MCMSG_CODE_ROBOT_NOTHING_TO_INIT = 0x4003000C |
"Nothing to init"
| uint32 INOS_MCMSG_CODE_ROBOT_NOTHING_TO_MOVE = 0x40030001 |
"Nothing to move"
| uint32 INOS_MCMSG_CODE_ROBOT_ON_NOT_ALLOWED = 0x40030012 |
"On of coupled axis not allowed"
| uint32 INOS_MCMSG_CODE_ROBOT_OSCI_CHECK = 0x40030302 |
"Oscillation detected"
| uint32 INOS_MCMSG_CODE_ROBOT_OUT_OF_ALLOWED_RANGE = 0x4003003D |
"Axis out of allowed range"
| uint32 INOS_MCMSG_CODE_ROBOT_PHASE_ERR = 0x4003031C |
"Phase error"
| uint32 INOS_MCMSG_CODE_ROBOT_POS_CHECK = 0x40030300 |
"Position check error"
| uint32 INOS_MCMSG_CODE_ROBOT_POS_OFFLINE = 0x4003030F |
"Position channel offline"
| uint32 INOS_MCMSG_CODE_ROBOT_POS_OVR = 0x40030301 |
"Position channel overrun detected"
| uint32 INOS_MCMSG_CODE_ROBOT_POS_RANGE = 0x40030200 |
"Requested position out of range"
| uint32 INOS_MCMSG_CODE_ROBOT_POS_WINDOW = 0x40030102 |
"Positioning window failed"
| uint32 INOS_MCMSG_CODE_ROBOT_POWER_WAIT_TIMEOUT = 0x4003003E |
"Timeout waiting for power"
| uint32 INOS_MCMSG_CODE_ROBOT_PULL_UNDERRUN = 0x40030109 |
"Pull underrun detected"
| uint32 INOS_MCMSG_CODE_ROBOT_PWM_100 = 0x40030717 |
"Pwm over 100%"
| uint32 INOS_MCMSG_CODE_ROBOT_PWM_WTG = 0x4003031D |
"Controller interrupt overrun"
| uint32 INOS_MCMSG_CODE_ROBOT_RAMP_CALC_FAILED = 0x40030201 |
"Ramp calculation failed"
| uint32 INOS_MCMSG_CODE_ROBOT_RAMP_CORE_MISMATCH = 0x40030206 |
"Ramp command called from wrong core"
| uint32 INOS_MCMSG_CODE_ROBOT_RAMP_LIMIT = 0x40030107 |
"Ramp limits exceeded"
| uint32 INOS_MCMSG_CODE_ROBOT_RAMP_OVERSAMPLE = 0x40030203 |
"Ramp samples do not fit oversampling"
| uint32 INOS_MCMSG_CODE_ROBOT_RAMP_WRN_CORE_MISMATCH = 0x40030601 |
"Ramp command called from wrong core"
| uint32 INOS_MCMSG_CODE_ROBOT_REF_MANDATORY = 0x40030020 |
"Reference support mandatory for this Init type"
| uint32 INOS_MCMSG_CODE_ROBOT_REFSEARCH_BACK_ZERO = 0x40030057 |
"Reference search back must not be zero"
| uint32 INOS_MCMSG_CODE_ROBOT_REFSEARCH_SAFE_CONTROLLER_NOT_AVAILABLE = 0x4003005A |
"Reference search type 'safe controller' not available for this axis"
| uint32 INOS_MCMSG_CODE_ROBOT_REFSEARCH_SECOND_FAILED = 0x40030059 |
"Searching the reference a second time failed"
| uint32 INOS_MCMSG_CODE_ROBOT_REFSEARCH_TOLERANCE_FAILED = 0x40030058 |
"Safe reference search out of tolerance"
| uint32 INOS_MCMSG_CODE_ROBOT_REFSEARCH_TOLERANCE_ZERO = 0x40030056 |
"Reference search tolerance must not be zero"
| uint32 INOS_MCMSG_CODE_ROBOT_REJECTED_SOS = 0x40030108 |
"Move not allowed, axis in SOS (safe operating stop)"
| uint32 INOS_MCMSG_CODE_ROBOT_RESOLVER = 0x40030317 |
"Resolver/SinCos error"
| uint32 INOS_MCMSG_CODE_ROBOT_SAFE_SYNC_FAILED = 0x40030305 |
"Safe sync failed"
| uint32 INOS_MCMSG_CODE_ROBOT_SAFETY_INPUT = 0x40030330 |
"Safety input missing"
| uint32 INOS_MCMSG_CODE_ROBOT_SEARCH_INPUT = 0x40030011 |
"Search input failed"
| uint32 INOS_MCMSG_CODE_ROBOT_SEARCH_REF_FAILED = 0x40030021 |
"Searching reference failed"
| uint32 INOS_MCMSG_CODE_ROBOT_SEARCH_REFERENCE_FAILED = 0x4003003C |
"Search reference failed"
| uint32 INOS_MCMSG_CODE_ROBOT_SHAPE_CONSERVATIVE_TOLERANCE = 0x40030048 |
"Conservative speed reduction and tolerance = 0.0 is not allowed"
| uint32 INOS_MCMSG_CODE_ROBOT_SHAPE_DISCONTINUOUS = 0x40030047 |
"Shape discontinuous error"
| uint32 INOS_MCMSG_CODE_ROBOT_SHAPE_LENGTH = 0x40030046 |
"Shape length error"
| uint32 INOS_MCMSG_CODE_ROBOT_SHARED_NOT_ACTIVE = 0x40030023 |
"Shared partner axis not active"
| uint32 INOS_MCMSG_CODE_ROBOT_SHARED_NOT_READY = 0x40030022 |
"Shared partner axis not ready"
| uint32 INOS_MCMSG_CODE_ROBOT_SHARED_ON_ERROR = 0x40030024 |
"Shared partner axis on error"
| uint32 INOS_MCMSG_CODE_ROBOT_SINCOS_ERROR = 0x40030325 |
"SinCos error"
| uint32 INOS_MCMSG_CODE_ROBOT_SINCOS_WEAK_SIGNAL = 0x4003071B |
"SinCos weak signal"
| uint32 INOS_MCMSG_CODE_ROBOT_SL2_ACTIVATE = 0x4003230D |
"Activation error"
| uint32 INOS_MCMSG_CODE_ROBOT_SL2_ASC_ERROR = 0x40032314 |
"SL2 automatic selfcalibration failed"
| uint32 INOS_MCMSG_CODE_ROBOT_SL2_EXTERN = 0x4003230E |
"External controller error"
| uint32 INOS_MCMSG_CODE_ROBOT_SL2_FEEDBACK_INVALID = 0x40032320 |
"SL2 invalid feedback code requested"
| uint32 INOS_MCMSG_CODE_ROBOT_SL2_NO_POS = 0x4003230C |
"No position channel available"
| uint32 INOS_MCMSG_CODE_ROBOT_SL2_OVR = 0x40032301 |
"Position channel overrun detected"
| uint32 INOS_MCMSG_CODE_ROBOT_SL2_POS_CHECK = 0x40032300 |
"Position check error"
| uint32 INOS_MCMSG_CODE_ROBOT_SL2_POS_OFFLINE = 0x4003230F |
"Position channel offline"
| uint32 INOS_MCMSG_CODE_ROBOT_SL2_POSACK_ERROR = 0x40032315 |
"SL2 position check error"
| uint32 INOS_MCMSG_CODE_ROBOT_SL2_POWEROK_ERROR = 0x40032317 |
"SL2 power error"
| uint32 INOS_MCMSG_CODE_ROBOT_SL2_RX_FIFO_OVERRUN = 0x40032310 |
"SL2 Rx fifo overrun"
| uint32 INOS_MCMSG_CODE_ROBOT_SL2_RX_STOPPED = 0x40032318 |
"SL2 RX stopped for some reason"
| uint32 INOS_MCMSG_CODE_ROBOT_SL2_TEMPOK_ERROR = 0x40032316 |
"SL2 temperature error"
| uint32 INOS_MCMSG_CODE_ROBOT_SL2_TX_FIFO_OVERRUN = 0x40032311 |
"SL2 Tx fifo overrun"
| uint32 INOS_MCMSG_CODE_ROBOT_SL2_TX_FIFO_UNDERRUN = 0x40032312 |
"SL2 Tx fifo underrun"
| uint32 INOS_MCMSG_CODE_ROBOT_SL2_TX_STOPPED = 0x40032319 |
"SL2 TX stopped for some reason"
| uint32 INOS_MCMSG_CODE_ROBOT_SLS_VIOLATION = 0x4003010A |
"Emergency stop due to upcoming SLS violation"
| uint32 INOS_MCMSG_CODE_ROBOT_SOS_VIOLATION = 0x4003010B |
"Emergency stop due to upcoming SOS violation"
| uint32 INOS_MCMSG_CODE_ROBOT_SPEED_ERROR_EXCEEDED = 0x40030324 |
"Speed error exceeded"
| uint32 INOS_MCMSG_CODE_ROBOT_SPEEDSET_HUGE_VALUE_JSON = 0x4003004B |
"The JSON string defining the speed set values is too big (too many tokens would be required to parse it)"
| uint32 INOS_MCMSG_CODE_ROBOT_SPEEDSET_VALUE_JSON_SYNTAX = 0x4003004C |
"The JSON string defining the speed set values has not the expected syntax"
| uint32 INOS_MCMSG_CODE_ROBOT_TESTMODE_ERRORS = 0x40030327 |
"Test Mode error"
| uint32 INOS_MCMSG_CODE_ROBOT_TURNS_INVALID = 0x4003002B |
"Turns per minute of axis doesn't match Vcmd_10x in controller"
| uint32 INOS_MCMSG_CODE_ROBOT_UCC_LOW = 0x40030710 |
"Ucc low"
| uint32 INOS_MCMSG_CODE_ROBOT_UCC_MAX = 0x40030312 |
"Ucc higher than max. allowed Ucc"
| uint32 INOS_MCMSG_CODE_ROBOT_UCC_MIN = 0x40030311 |
"Ucc smaller than min. allowed Ucc"
| uint32 INOS_MCMSG_CODE_ROBOT_UCC_ON = 0x40030711 |
"Ucc on"
| uint32 INOS_MCMSG_CODE_ROBOT_UNEXPECTED = 0x40030719 |
"Unexpected error"
| uint32 INOS_MCMSG_CODE_ROBOT_UNKNOWN_AXIS = 0x40030002 |
"Unknown axis"
| uint32 INOS_MCMSG_CODE_ROBOT_UNKNOWN_CALIB_DIR = 0x40030039 |
"Unknown calib direction"
| uint32 INOS_MCMSG_CODE_ROBOT_UNKNOWN_CALIB_TYPE = 0x40030038 |
"Unknown calib type"
| uint32 INOS_MCMSG_CODE_ROBOT_UNKNOWN_INIT_DIR = 0x4003000E |
"Unknown init direction"
| uint32 INOS_MCMSG_CODE_ROBOT_UNKNOWN_INIT_EDGE = 0x4003000F |
"Unknown init edge"
| uint32 INOS_MCMSG_CODE_ROBOT_UNKNOWN_INIT_TYPE = 0x4003000D |
"Unknown init type"
| uint32 INOS_MCMSG_CODE_ROBOT_UNKNOWN_PARAM = 0x40030003 |
"Unknown param set"
| uint32 INOS_MCMSG_CODE_ROBOT_UNKNOWN_SENSOR = 0x40030045 |
"Unknown sensor"
| uint32 INOS_MCMSG_CODE_ROBOT_UNKNOWN_SHAPE = 0x40030030 |
"Unknown shape"
| uint32 INOS_MCMSG_CODE_ROBOT_UNKNOWN_SYNCPOINT = 0x40030008 |
"Unknown sync point"
| uint32 INOS_MCMSG_CODE_ROBOT_UNKNOWN_TRG_TYPE = 0x40030006 |
"Unknown trigger type"
| uint32 INOS_MCMSG_CODE_ROBOT_VALVE_BUSY = 0x40032324 |
"Command not allowed, valve already busy"
| uint32 INOS_MCMSG_CODE_ROBOT_VALVE_GEN_ERROR = 0x40032321 |
"Unspecified valve error"
| uint32 INOS_MCMSG_CODE_ROBOT_VALVE_TIMEOUT = 0x40032323 |
"Valve timeout"
| uint32 INOS_MCMSG_CODE_ROBOT_VALVE_UCC_ERROR = 0x40032322 |
"Valve UCC error"
| uint32 INOS_MCMSG_CODE_ROBOT_VMAX = 0x40030318 |
"Vmax exceeded"
| uint32 INOS_MCMSG_CODE_ROBOT_VMAX_REACHED = 0x40030204 |
"Allowed Vmax reached"
| uint32 INOS_MCMSG_CODE_ROBOT_WHEEL_BUSY = 0x4003002E |
"Wheel not allowed, axis busy"
| uint32 INOS_MCMSG_CODE_ROBOT_ZERO_BLOCKED = 0x40030010 |
"Zero input blocked"
| uint32 INOS_MCMSG_CODE_ROBOT_ZERO_OR_REF_MAND = 0x4003001E |
"Reference or zero support mandatory for this Init type"
| uint32 INOS_MCMSG_CODE_SIO_ABORT_CHAR = 0x40130020 |
"Abort character received"
| uint32 INOS_MCMSG_CODE_SIO_CANCELED = 0x40130029 |
"Command canceled by a ResetDevice"
| uint32 INOS_MCMSG_CODE_SIO_CHANNEL = 0x40130028 |
"Unknown SIO channel"
| uint32 INOS_MCMSG_CODE_SIO_DEBUG_MODE = 0x40130027 |
"Channel is in debug mode"
| uint32 INOS_MCMSG_CODE_SIO_DSR_MISSING = 0x40130025 |
"DSR input missing"
| uint32 INOS_MCMSG_CODE_SIO_ERROR = 0x40130000 |
"Unknown SIO error"
| uint32 INOS_MCMSG_CODE_SIO_FRAMING_ERR = 0x40130021 |
"Framing error"
| uint32 INOS_MCMSG_CODE_SIO_INP_OVERFLOW = 0x40130024 |
"Input buffer overflow"
| uint32 INOS_MCMSG_CODE_SIO_INTERNAL_ERROR = 0x40130005 |
"Internal communication error"
| uint32 INOS_MCMSG_CODE_SIO_MAXCHARS = 0x4013002A |
"Max. number of chars received"
| uint32 INOS_MCMSG_CODE_SIO_OVERRUN_ERR = 0x40130023 |
"Overrun error"
| uint32 INOS_MCMSG_CODE_SIO_PARITY_ERR = 0x40130022 |
"Parity error"
| uint32 INOS_MCMSG_CODE_SIO_TIMEOUT = 0x40130026 |
"Communication timeout"
| uint32 INOS_MCMSG_CODE_TARGET_ASSERT = 0x40100002 |
"Target on ASSERT"
| uint32 INOS_MCMSG_CODE_TARGET_BOOTING = 0x40100006 |
"Target is booting ..."
| uint32 INOS_MCMSG_CODE_TARGET_GUARD = 0x4010000A |
"System guard occured"
| uint32 INOS_MCMSG_CODE_TARGET_NOT_CORE0 = 0x40100005 |
"Code intended for core 0 was executed by some other core"
| uint32 INOS_MCMSG_CODE_TARGET_RAM_FAILURE = 0x40100003 |
"Target RAM failure"
| uint32 INOS_MCMSG_CODE_TARGET_REALTIME_MUTEX = 0x40100008 |
"CINOSMutex::Request called from a realtime task, which is not allowed"
| uint32 INOS_MCMSG_CODE_TARGET_REALTIME_SYNC = 0x40100009 |
"CINOSSync::Wait called from a realtime task, which is not allowed"
| uint32 INOS_MCMSG_CODE_TARGET_TIMING_ERROR = 0x40100007 |
"Target 'timing error' occurred (see Eventlog for more info)"
| uint32 INOS_MCMSG_CODE_TARGET_TRAP = 0x40100001 |
"Target on TRAP"
| uint32 INOS_MCMSG_CODE_TARGET_WATCHDOG = 0x40100004 |
"Target watchdog occurred"
| uint32 INOS_MCMSG_CODE_TASK_QUEUE_DUPLICATE = 0x40001001 |
"Put ignored due to duplicate detection"
| uint32 INOS_MCMSG_CODE_TASK_QUEUE_FLUSH_OWNER = 0x40001002 |
"Only the owner is allowed to flush the queue"
| uint32 INOS_MCMSG_CODE_TASK_QUEUE_FULL = 0x40001000 |
"Task queue is full"
| uint32 INOS_MCMSG_CODE_TSK_UNKNOWN_EXCEPTION = 0x40000200 |
"Unknown unhandled exception occured"
| uint32 INOS_MCMSG_CODE_TSKEX_CANCELED = 0x46000000 |
"Command canceled"
| uint32 INOS_MCMSG_CODE_TSKEX_CMD_NO_FUNCTION = 0x40000110 |
"Command used with function"
| uint32 INOS_MCMSG_CODE_TSKEX_CMD_NO_OBJECT = 0x4000010F |
"Command used with no object set"
| uint32 INOS_MCMSG_CODE_TSKEX_CMD_NO_TASK = 0x4000010E |
"Command used with no task set"
| uint32 INOS_MCMSG_CODE_TSKEX_DEF_HANDLE_UNSUPPORTED = 0x40000105 |
"Deferred message handle does not support commands"
| uint32 INOS_MCMSG_CODE_TSKEX_ERROR = 0x49000000 |
"Command ended with an error"
| uint32 INOS_MCMSG_CODE_TSKEX_FAILED = 0x48000000 |
"Command failed"
| uint32 INOS_MCMSG_CODE_TSKEX_FASTLOAD_DATA_TRANSFER = 0x40000112 |
"FastLoad invalid datatransfer method given"
| uint32 INOS_MCMSG_CODE_TSKEX_FASTLOAD_PORT_NUMBER = 0x40000111 |
"FastLoad invalid port number given"
| uint32 INOS_MCMSG_CODE_TSKEX_FATAL = 0x4A000000 |
"Command ended with a fatal error"
| uint32 INOS_MCMSG_CODE_TSKEX_GENERIC = 0x40000000 |
"Not further specified failure detected by the McRobot base framework"
| uint32 INOS_MCMSG_CODE_TSKEX_IGNORED = 0x43000000 |
"Command ignored"
| uint32 INOS_MCMSG_CODE_TSKEX_INCO_TYPE_MISMATCH = 0x40000004 |
"INCO type mismatch"
| uint32 INOS_MCMSG_CODE_TSKEX_INCO_TYPE_UNSUPPTORED = 0x40000003 |
"INCO type is not supported"
| uint32 INOS_MCMSG_CODE_TSKEX_INCOMPLETE = 0x42000000 |
"Command incomplete"
| uint32 INOS_MCMSG_CODE_TSKEX_INPUT_QUEUE_FULL = 0x40000106 |
"Adding the 'TaskExMsg' to the task's input queue failed due to 'queue full'"
| uint32 INOS_MCMSG_CODE_TSKEX_INVALID_COREID = 0x40000107 |
"Invalid core id requested"
| uint32 INOS_MCMSG_CODE_TSKEX_NULLPTR_MSG = 0x4000010C |
"Tried to put a 'TaskExMsg' to the task's input queue which is a 'nullptr'"
| uint32 INOS_MCMSG_CODE_TSKEX_OVERSIZED_RESULT = 0x4000010A |
"Oversized result detected"
| uint32 INOS_MCMSG_CODE_TSKEX_PARAM_MISSING = 0x40000002 |
"Mandatory param missing"
| uint32 INOS_MCMSG_CODE_TSKEX_PAUSED = 0x44000000 |
"Command paused"
| uint32 INOS_MCMSG_CODE_TSKEX_REJECTED = 0x47000000 |
"Command rejected"
| uint32 INOS_MCMSG_CODE_TSKEX_SKIPPED = 0x41000000 |
"Command skipped"
| uint32 INOS_MCMSG_CODE_TSKEX_STOPPED = 0x45000000 |
"Command stopped"
| uint32 INOS_MCMSG_CODE_TSKEX_TIMEOUT = 0x4B000000 |
"Command ended with a timeout"
| uint32 INOS_MCMSG_CODE_TSKEX_TRGMSG_BUSID = 0x4000010D |
"Triggered message with invalid bus id"
| uint32 INOS_MCMSG_CODE_TSKEX_TRGMSG_MULTICORE = 0x4000010B |
"The given fieldbus does not support triggered messages on the requested core"
| uint32 INOS_MCMSG_CODE_TSKEX_UNKNOWN = 0x40000001 |
"Unknown command"
| uint32 INOS_MCMSG_CODE_TSKEX_UNKNOWN_CMD_HOOK = 0x40000109 |
"Unknown command hook"
| uint32 INOS_MCMSG_CODE_TSKEX_VAR_FAILED = 0x40000100 |
"Variable access failed"
| uint32 INOS_MCMSG_CODE_TSKEX_VAR_MAX = 0x40000104 |
"Variable maximum reached"
| uint32 INOS_MCMSG_CODE_TSKEX_VAR_MIN = 0x40000103 |
"Variable minimum reached"
| uint32 INOS_MCMSG_CODE_TSKEX_VAR_NOT_FOUND = 0x40000101 |
"Variable not found"
| uint32 INOS_MCMSG_CODE_TSKEX_VAR_READ_ONLY = 0x40000102 |
"Variable is read only"
| uint32 INOS_MCMSG_CODE_TSKEX_WRONG_PARAMS = 0x40000108 |
"Wrong param type detected"
| INOS_MCMSG_TYPE_FATAL {\"property\":{\"category\":\"safety\",\"delay\":{\"acknowledge\":10000}}}") uint32 INOS_MCTARGET_SAFETY_VERIFY_FAILED = 0x40340400 |
"Verifying configuration failed, please reboot!"
| INOS_MCMSG_TYPE_INFO {\"property\":{\"category\":\"safety\",\"authlevel\":1}}") uint32 INOS_MCTARGET_SAFETY_SETUP_VERIFY_CRC = 0x40340321 |
"Please confirm correctness of safety configuration"
| uint32 INOS_MCTARGET_CANBUS_BUS_INIT_FAILED = 0x403F1009 |
"Error in initializing CAN bus"
| uint32 INOS_MCTARGET_CANBUS_GENERAL = 0x403F1001 |
"General error"
| uint32 INOS_MCTARGET_CANBUS_INVALID_BAUDRATE = 0x403F1008 |
"Invalid CAN bus baudrate"
| uint32 INOS_MCTARGET_CANBUS_INVALID_CHANNEL_INDEX = 0x403F1003 |
"Invalid channel index given"
| uint32 INOS_MCTARGET_CANBUS_INVALID_CHANNEL_NAME = 0x403F1005 |
"Invalid channel name detected (call Indel)"
| uint32 INOS_MCTARGET_CANBUS_NOT_IMPLEMENTED = 0x403F1002 |
"Method not implemented"
| uint32 INOS_MCTARGET_CANBUS_PROXY_INIT_FAILED = 0x403F1007 |
"Calling Init on canbus slave failed"
| uint32 INOS_MCTARGET_CANBUS_RECEIVE_TIMEOUT = 0x403F1006 |
"Timeout waiting for frame"
| uint32 INOS_MCTARGET_CANBUS_TX_OVERRUN = 0x403F100A |
"No buffers left for sending"
| uint32 INOS_MCTARGET_CANBUS_UNKNOWN_CHANNEL_NAME = 0x403F1004 |
"Unknown channel name given"
| uint32 INOS_MCTARGET_CANBUS_WRONG_FIRMWARE = 0x403F100B |
"Firmware not as expected"
| uint32 INOS_MCTARGET_CANCAP_GENERAL = 0x403F2001 |
"General error"
| uint32 INOS_MCTARGET_CANCAP_INTERFACE_UNKNOWN = 0x403F2002 |
"Unknown interface name given"
| uint32 INOS_MCTARGET_COMM_GENERAL = 0x40330001 |
"General error"
| uint32 INOS_MCTARGET_COMM_TARGET_OFFLINE = 0x40330003 |
"Target is offline"
| uint32 INOS_MCTARGET_COMM_UNKNOWN_TARGET = 0x40330002 |
"Unknown target given"
| uint32 INOS_MCTARGET_DATA_ATTRIBUTE_NOT_FOUND = 0x40310003 |
"Data attribute not found"
| uint32 INOS_MCTARGET_DATA_GENERAL = 0x40310000 |
"General data error"
| uint32 INOS_MCTARGET_DATA_OBJECT_NOT_FOUND = 0x40310001 |
"Data object not found"
| uint32 INOS_MCTARGET_DATA_PROPERTY_NOT_FOUND = 0x40310002 |
"Data property not found"
| uint32 INOS_MCTARGET_DEX_DUPLICATE_ADDRESS_SWITCH = 0x403F0003 |
"Duplicate address switch given"
| uint32 INOS_MCTARGET_DEX_DUPLICATE_IP_ADDRESS = 0x403F0007 |
"Duplicate ip address given"
| uint32 INOS_MCTARGET_DEX_GENERAL = 0x403F0001 |
"General error"
| uint32 INOS_MCTARGET_DEX_INVALID_ADDRESS_SWITCH = 0x403F0002 |
"Invalid address switch given"
| uint32 INOS_MCTARGET_DEX_INVALID_IP_ADDRESS = 0x403F0006 |
"Invalid ip address given"
| uint32 INOS_MCTARGET_DEX_INVALID_WORDS = 0x403F0005 |
"Invalid number of words given"
| uint32 INOS_MCTARGET_DEX_UNKNOWN_ADDRESS_SWITCH = 0x403F0004 |
"Unknown address switch given"
| uint32 INOS_MCTARGET_DEX_UNKNOWN_MODULE = 0x403F0008 |
"Unknown DEX module given"
| uint32 INOS_MCTARGET_ENTROPY_BIASED = 0x403D0003 |
"Entropy bias: collected random data is not cryptographically secure"
| uint32 INOS_MCTARGET_ENTROPY_GENERAL = 0x403D0001 |
"General error"
| uint32 INOS_MCTARGET_ENTROPY_UNDERFLOW = 0x403D0002 |
"Not enough entropy to generate random bytes (e.g. used by OPC UA). System load too high?"
| uint32 INOS_MCTARGET_ENVIRONMENT_ALREAD_EXISTS = 0x40370003 |
"Variable already exists"
| uint32 INOS_MCTARGET_ENVIRONMENT_FLASH_LOCK_FAILED = 0x40370007 |
"Failed to lock environment flash"
| uint32 INOS_MCTARGET_ENVIRONMENT_FLASH_NOT_FOUND = 0x40370005 |
"Environment flash not found"
| uint32 INOS_MCTARGET_ENVIRONMENT_FLASH_UNLOCK_FAILED = 0x40370006 |
"Failed to unlock environment flash"
| uint32 INOS_MCTARGET_ENVIRONMENT_GENERAL = 0x40370001 |
"General error"
| uint32 INOS_MCTARGET_ENVIRONMENT_PERSISTENT_NOT_SUPPORTED = 0x40370004 |
"Persistent environment write not supported"
| uint32 INOS_MCTARGET_ENVIRONMENT_UNKNOWN_VARIABLE = 0x40370002 |
"Unknown variable"
| uint32 INOS_MCTARGET_ETHCAP_GENERAL = 0x403A0001 |
"General error"
| uint32 INOS_MCTARGET_ETHCAP_INTERFACE_UNKNOWN = 0x403A0002 |
"Unknown interface name given"
| uint32 INOS_MCTARGET_FIELDBUS_MASTER_DUPLICATE_BUSID = 0x40351002 |
"Duplicate fieldbus id detected"
| uint32 INOS_MCTARGET_FIELDBUS_MASTER_GENERAL = 0x40351001 |
"General error"
| uint32 INOS_MCTARGET_FIELDBUS_MASTER_INVALID_BUSID = 0x40351003 |
"Invalid fieldbus id detected"
| uint32 INOS_MCTARGET_FIELDBUS_SLAVE_BUSNUMBER_NOT_AVAILABLE = 0x40350002 |
"Fieldbus number not available"
| uint32 INOS_MCTARGET_FIELDBUS_SLAVE_GENERAL = 0x40350001 |
"General error"
| uint32 INOS_MCTARGET_FIRMWARE_COP_ADDR_OVERRUN = 0x403F3064 |
"flash address overrun"
| uint32 INOS_MCTARGET_FIRMWARE_COP_ADDR_PROTECTED = 0x403F3063 |
"flash address protected"
| uint32 INOS_MCTARGET_FIRMWARE_COP_CYCLE_BUSY = 0x403F3066 |
"cycle time not writable"
| uint32 INOS_MCTARGET_FIRMWARE_COP_MODUL_NOT_FOUND = 0x403F3062 |
"module not found"
| uint32 INOS_MCTARGET_FIRMWARE_COP_TIMEOUT = 0x403F3060 |
"timeout"
| uint32 INOS_MCTARGET_FIRMWARE_COP_WRONG_LENGTH = 0x403F3065 |
"wrong length"
| uint32 INOS_MCTARGET_FIRMWARE_DATALOADADDR = 0x403F3102 |
"no data load address"
| uint32 INOS_MCTARGET_FIRMWARE_ERASE = 0x403F3101 |
"erase failed"
| uint32 INOS_MCTARGET_FIRMWARE_FILE_SIZE = 0x403F3020 |
"-l length is bigger than the binary"
| uint32 INOS_MCTARGET_FIRMWARE_GENERAL = 0x403F3000 |
"General error"
| uint32 INOS_MCTARGET_FIRMWARE_IMAGE_CRC = 0x403F3003 |
"wrong image crc"
| uint32 INOS_MCTARGET_FIRMWARE_NO_ISP_SUPPORT = 0x403F3015 |
"wrong spi id"
| uint32 INOS_MCTARGET_FIRMWARE_POLL_TIMEOUT = 0x403F3050 |
"timeout"
| uint32 INOS_MCTARGET_FIRMWARE_PROGRAM = 0x403F3100 |
"program failed"
| uint32 INOS_MCTARGET_FIRMWARE_SPI_SPI_NOTBLANK = 0x403F3061 |
"flash not blank"
| uint32 INOS_MCTARGET_FIRMWARE_SPI_UNSUPORTEDCMD = 0x403F3070 |
"Unsupported spi command"
| uint32 INOS_MCTARGET_FIRMWARE_UNKNOWN_IMAGE = 0x403F3002 |
"Unknown image given"
| uint32 INOS_MCTARGET_FIRMWARE_VERIFY = 0x403F3014 |
"verification failed"
| uint32 INOS_MCTARGET_FIRMWARE_WRONG_ARGUMENTS = 0x403F3010 |
"wrong arguments"
| uint32 INOS_MCTARGET_GENERIC = 0x40300000 |
"Generic error"
| uint32 INOS_MCTARGET_GINSAM3_FPGA_TOO_OLD = 0x40300004 |
"GIN-SAM3 requires a FPGA version of at least 0x1F (see 'Target.Prop.GalRevision')"
| uint32 INOS_MCTARGET_IMAGE_GENERAL = 0x40320001 |
"General error"
| uint32 INOS_MCTARGET_IMAGE_ID_UNKNOWN = 0x40320003 |
"Unknown image id"
| uint32 INOS_MCTARGET_IMAGE_INVALID_ADDRESS_GIVEN = 0x40320004 |
"Invalid address given"
| uint32 INOS_MCTARGET_IMAGE_TRANSFER_GENERAL = 0x40321001 |
"General error"
| uint32 INOS_MCTARGET_IMAGE_TRANSFER_SEND_FAILED = 0x40321002 |
"Sending image failed"
| uint32 INOS_MCTARGET_IMAGE_TYPE_NOT_SUPPORTED = 0x40320002 |
"Image type not supported"
| uint32 INOS_MCTARGET_KERNEL_LOGGER_ACTUAL_INVALID_COREID = 0x403E000B |
"Invalid coreid given"
| uint32 INOS_MCTARGET_KERNEL_LOGGER_ACTUAL_UNKNOWN = 0x403E000C |
"Unknown actual given"
| uint32 INOS_MCTARGET_KERNEL_LOGGER_BUFFER_ALREADY_CREATED = 0x403E0002 |
"Logger buffer already created"
| uint32 INOS_MCTARGET_KERNEL_LOGGER_GENERAL = 0x403E0001 |
"General error"
| uint32 INOS_MCTARGET_KERNEL_LOGGER_NOT_ENOUGH_MEMORY = 0x403E0003 |
"Not enough memory to create logger buffer"
| uint32 INOS_MCTARGET_KERNEL_LOGGER_PROPERTY_SET_NOT_ALLOWED = 0x403E0007 |
"Property set not allowed, logger running"
| uint32 INOS_MCTARGET_KERNEL_LOGGER_PROPERTY_SET_TASK_UNKNOWN = 0x403E0008 |
"Unknown task name given"
| uint32 INOS_MCTARGET_KERNEL_LOGGER_PROPERTY_TYPE_WRONG = 0x403E0006 |
"Property type wrong"
| uint32 INOS_MCTARGET_KERNEL_LOGGER_PROPERTY_UNKNOWN = 0x403E0005 |
"Unknown property given"
| uint32 INOS_MCTARGET_KERNEL_LOGGER_START_TYPE_UNKNOWN = 0x403E0004 |
"Unknown logger start type given"
| uint32 INOS_MCTARGET_KERNEL_LOGGER_TRIGGER_TESTPOINT_NA = 0x403E000A |
"Requested trigger testpoint not available"
| uint32 INOS_MCTARGET_KERNEL_LOGGER_TRIGGER_TYPE_UNKNOWN = 0x403E0009 |
"Unknown trigger type given"
| uint32 INOS_MCTARGET_MOTOR_GENERAL = 0x40360001 |
"General error"
| uint32 INOS_MCTARGET_MOTOR_RESOLVER_ADJUSTMENT_FAILED_TARGET = 0x40360002 |
"Resolver adjustment failed"
| uint32 INOS_MCTARGET_ONNX_GENERAL = 0x403F5000 |
"General error"
| uint32 INOS_MCTARGET_ONNX_MODEL_ALREADY_LOCKED = 0x403F5002 |
"Model already locked"
| uint32 INOS_MCTARGET_ONNX_MODEL_CONTEXT_ALLOC_FAILED = 0x403F5003 |
"Failed to allocate context memory"
| uint32 INOS_MCTARGET_ONNX_MODEL_CONTEXT_INVALID = 0x403F5004 |
"Invalid model context given"
| uint32 INOS_MCTARGET_ONNX_MODEL_NAME_UNKNOWN = 0x403F5001 |
"Unknown model name given"
| uint32 INOS_MCTARGET_OPCUA_SERVER_CERT_MISSING = 0x403B0004 |
"OPC UA Server security certificate missing"
| uint32 INOS_MCTARGET_OPCUA_SERVER_CLIENTCERT_MISSING = 0x403B0006 |
"OPC UA Server trust list certificate not found"
| uint32 INOS_MCTARGET_OPCUA_SERVER_GENERAL = 0x403B0000 |
"OPC UA Server General error. Check Eventlog for more info"
| uint32 INOS_MCTARGET_OPCUA_SERVER_PRIVKEY_MISSING = 0x403B0005 |
"OPC UA Server private key missing"
| uint32 INOS_MCTARGET_OPCUA_SERVER_SECURITY_CONFIG_MISSING = 0x403B0003 |
"OPC UA Server security configuration missing"
| uint32 INOS_MCTARGET_OPCUA_SERVER_SECURITY_POLICY_UNKNOWN = 0x403B0007 |
"OPC UA Server does not support a configured security policy"
| uint32 INOS_MCTARGET_OPCUA_SERVER_TERMINATED = 0x403B0008 |
"OPC UA Server terminated unexpectedly"
| uint32 INOS_MCTARGET_OPCUA_SERVER_UA_FAILED = 0x403B0001 |
"OPC UA Server: An open62541 library function failed"
| uint32 INOS_MCTARGET_OPCUA_SERVER_URI_MISSING = 0x403B0002 |
"OPC UA Server application URI must be specified"
| uint32 INOS_MCTARGET_RESOURCE_UNKNOWN = 0x40300003 |
"Unknown resource name given"
| uint32 INOS_MCTARGET_SAFETY_BINARY_INVALID = 0x40340003 |
"Safety binary invalid"
| uint32 INOS_MCTARGET_SAFETY_BINARY_MISSING = 0x40340002 |
"Safety binary missing"
| uint32 INOS_MCTARGET_SAFETY_BINARY_SIZE_MISMATCH = 0x40340004 |
"Safety binary size mismatch"
| uint32 INOS_MCTARGET_SAFETY_COMM_FAILED = 0x40340100 |
"General communication failure"
| INOS_MCMSG_FLAG_NONE uint32 INOS_MCTARGET_SAFETY_COMM_READ08_FAILED = 0x40340101 |
"Reading an uint8 from safety device failed"
| INOS_MCMSG_FLAG_NONE uint32 INOS_MCTARGET_SAFETY_COMM_READ16_FAILED = 0x40340103 |
"Reading an uint16 from safety device failed"
| INOS_MCMSG_FLAG_NONE uint32 INOS_MCTARGET_SAFETY_COMM_READ32_FAILED = 0x40340105 |
"Reading an uint32 from safety device failed"
| INOS_MCMSG_FLAG_NONE uint32 INOS_MCTARGET_SAFETY_COMM_READ64_FAILED = 0x40340107 |
"Reading an uint64 from safety device failed"
| INOS_MCMSG_FLAG_NONE uint32 INOS_MCTARGET_SAFETY_COMM_TIMEOUT_FAILED = 0x40340110 |
"Command failed, no reaction from safety device"
| INOS_MCMSG_FLAG_NONE uint32 INOS_MCTARGET_SAFETY_COMM_WRITE08_FAILED = 0x40340102 |
"Writing an uint8 to safety device failed"
| INOS_MCMSG_FLAG_NONE uint32 INOS_MCTARGET_SAFETY_COMM_WRITE16_FAILED = 0x40340104 |
"Writing an uint16 to safety device failed"
| INOS_MCMSG_FLAG_NONE uint32 INOS_MCTARGET_SAFETY_COMM_WRITE32_FAILED = 0x40340106 |
"Writing an uint32 to safety device failed"
| INOS_MCMSG_FLAG_NONE uint32 INOS_MCTARGET_SAFETY_COMM_WRITE64_FAILED = 0x40340108 |
"Writing an uint64 to safety device failed"
| INOS_MCMSG_FLAG_NONE uint32 INOS_MCTARGET_SAFETY_CONFIRM_STO_FAILED = 0x4034000D |
"Confirming STO in safety controller failed"
| uint32 INOS_MCTARGET_SAFETY_CONFIRM_STO_INVALID_NAME = 0x4034000E |
"Confirming STO invalid device name given"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_AllAdc24VDiffTooLarge = 0x4034057E |
"Difference in ADC measurement of 24V between CPU A and B is too large"
| INOS_MCMSG_FLAG_NONE uint32 INOS_MCTARGET_SAFETY_DEVICE_AllAdcMalfunction = 0x4034057D |
"Adc register didn't change, no new value was sampled"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_AllAdcSafe24VDiffTooLarge = 0x4034057F |
"Difference in ADC measurement of Safe24V between CPU A and B is too large"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_AllConfigContainerDamaged = 0x4034055F |
"Configuration container periodic health test failed"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_AllConfigCrcWrong = 0x4034055B |
"Configuration container crc value wrong"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_AllConfigFieldbusPosWrong = 0x4034055E |
"Configuration container fieldbus position wrong"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_AllConfigLengthWrong = 0x4034055A |
"Configuration container length wrong"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_AllConfigProductIdWrong = 0x4034055C |
"Configuration container product id wrong"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_AllConfigVersionWrong = 0x4034055D |
"Configuration container version wrong"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_AllContConfTestIncomplete = 0x40340542 |
"Configuration container tests were not completed within 1 hour"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_AllCycleOverrun = 0x4034056E |
"Main cycle overrun, watchdog has stopped the system"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_AllDevPomInit = 0x40340549 |
"Error in initialisation of power monitoring device"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_AllDevPomTestIncomplete = 0x40340540 |
"Power monitoring device tests were not completed within 1 hour"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_AllFlashEraseError = 0x40340583 |
"Error while erasing flash sector"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_AllFlashReadError = 0x40340582 |
"Error while reading flash"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_AllFlashWriteError = 0x40340584 |
"Error while writing flash"
| INOS_MCMSG_FLAG_NONE uint32 INOS_MCTARGET_SAFETY_DEVICE_AllHwCPUFail = 0x40340508 |
"Periodic cpu test has failed"
| INOS_MCMSG_FLAG_NONE uint32 INOS_MCTARGET_SAFETY_DEVICE_AllHwCPUFailFirst = 0x40340507 |
"First cpu test has not completed"
| INOS_MCMSG_FLAG_NONE uint32 INOS_MCTARGET_SAFETY_DEVICE_AllHwCPUFailInit = 0x40340506 |
"Initial cpu test has failed"
| INOS_MCMSG_FLAG_NONE uint32 INOS_MCTARGET_SAFETY_DEVICE_AllHwFirmwareFail = 0x4034050E |
"Periodic firmware test has failed"
| INOS_MCMSG_FLAG_NONE uint32 INOS_MCTARGET_SAFETY_DEVICE_AllHwFirmwareFailInit = 0x4034050C |
"Initial firmware test has failed"
| INOS_MCMSG_FLAG_NONE uint32 INOS_MCTARGET_SAFETY_DEVICE_AllHwFirmwareFailSetup = 0x4034050D |
"Setting up periodic firmware test has failed"
| INOS_MCMSG_FLAG_NONE uint32 INOS_MCTARGET_SAFETY_DEVICE_AllHwMemoryFail = 0x4034050B |
"Periodic memory test has failed"
| INOS_MCMSG_FLAG_NONE uint32 INOS_MCTARGET_SAFETY_DEVICE_AllHwMemoryFailInit = 0x40340509 |
"Initial memory test has failed"
| INOS_MCMSG_FLAG_NONE uint32 INOS_MCTARGET_SAFETY_DEVICE_AllHwMemoryFailSetup = 0x4034050A |
"Setting up periodic memory test has failed"
| INOS_MCMSG_FLAG_NONE uint32 INOS_MCTARGET_SAFETY_DEVICE_AllHwStackFail = 0x40340505 |
"Periodic stack test has failed"
| INOS_MCMSG_FLAG_NONE uint32 INOS_MCTARGET_SAFETY_DEVICE_AllHwStackFailInit = 0x40340502 |
"Initialising stack test has failed"
| INOS_MCMSG_FLAG_NONE uint32 INOS_MCTARGET_SAFETY_DEVICE_AllHwStackFailInitTest = 0x40340503 |
"Initial run of stack test has failed"
| INOS_MCMSG_FLAG_CONFIRM uint32 INOS_MCTARGET_SAFETY_DEVICE_AllHwStackFailOverflow = 0x40340501 |
"Initial stack test has failed as stack pointer has already overflowed"
| INOS_MCMSG_FLAG_NONE uint32 INOS_MCTARGET_SAFETY_DEVICE_AllHwStackFailSetup = 0x40340504 |
"Setting up periodic stack test has failed"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_AllIntCommDma13Enabled = 0x4034051E |
"Spi dma 1 stream 3 couldn't be disabled in time"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_AllIntCommDma14Enabled = 0x4034051F |
"Spi dma 1 stream 4 couldn't be disabled in time"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_AllIntCommToExtData = 0x40340528 |
"Spi external comm address doesn't match"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_AllIntCommToExtRx = 0x40340527 |
"Spi external comm didn't finish receiving in time"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_AllIntCommToExtTx = 0x40340526 |
"Spi external comm didn't finish transmitting in time"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_AllIntCommToIntTx = 0x40340524 |
"Spi internal comm didn't finish transmitting in time"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_AllIntCommToXRx = 0x40340522 |
"Spi exchange didn't finish receiving in time"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_AllMgrConfigState = 0x40340547 |
"Wrong value of configuration manager state"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_AllMgrCtTestIncomplete = 0x4034053F |
"CPU manager device tests were not completed within 1 hour"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_AllMgrRpState = 0x4034054A |
"Wrong value of module state in reporting manager"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_AllMgrRpTestIncomplete = 0x40340541 |
"Reporting manager tests were not completed within 1 hour"
| INOS_MCMSG_FLAG_NONE uint32 INOS_MCTARGET_SAFETY_DEVICE_AllPowerError24VTooHigh = 0x40340579 |
"Measured 24V is too high"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_AllPowerError24VTooLow = 0x40340578 |
"Measured 24V is too low"
| INOS_MCMSG_FLAG_NONE uint32 INOS_MCTARGET_SAFETY_DEVICE_AllPowerError3_3VTooHigh = 0x4034057B |
"Measured 3.3V is too high"
| INOS_MCMSG_FLAG_NONE uint32 INOS_MCTARGET_SAFETY_DEVICE_AllPowerError3_3VTooLow = 0x4034057A |
"Measured 3.3V is too low"
| INOS_MCMSG_FLAG_NONE uint32 INOS_MCTARGET_SAFETY_DEVICE_AllPowerErrorGNDTooHigh = 0x4034057C |
"Measured ground is too high"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_AllPowerErrorVRefIntTooHigh = 0x40340581 |
"Measured VRefInt is too high"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_AllPowerErrorVRefIntTooLow = 0x40340580 |
"Measured VRefInt is too low"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_AllSchedTestIncomplete = 0x4034053E |
"Too many cycles used for one full test cycle"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_AllSchedTestMaxCycLoop = 0x4034053D |
"Too many cycles used per scheduler loop"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_AllSchedTestMaxCycState = 0x4034053C |
"Too many cycles used per state, scheduler state is not increasing anymore"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_AllSetClockFail = 0x40340518 |
"Clock speed could not be set correctly"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_AllStartupErrorSize = 0x40340552 |
"Startup error list size error"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_AllSynchClock = 0x40340517 |
"Clock speed doesn't match between cpu A and B"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_AllSynchSchedState = 0x40340515 |
"Scheduler state on cpu A and B doesn't match"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_AllSynchTwin = 0x40340516 |
"Spi synchronisation between cpu A and B failed"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_AllTrapBusFault = 0x40340572 |
"Cpu bus fault"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_AllTrapHardFault = 0x40340570 |
"Cpu hard fault"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_AllTrapMemManage = 0x40340571 |
"Cpu mem manage fault"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_AllTrapNmi = 0x4034056F |
"Cpu nmi trap"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_AllTrapUsageFault = 0x40340573 |
"Cpu usage fault"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_CpuAExtCommDma12Enabled = 0x40340532 |
"Dma 1 stream 2 couldn't be disabled in time"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_CpuAExtCommDma15Enabled = 0x40340533 |
"Dma 1 stream 5 couldn't be disabled in time"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_CpuAExtCommRandomNumber = 0x40340536 |
"Spi external dma comm didn't finish transmitting in time"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_CpuAExtCommToDmaFinished = 0x40340535 |
"Spi external dma comm didn't finish transmitting in time"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_CpuAIntCommToExtInput = 0x40340525 |
"Spi external comm has failed chip select synchronisation"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_CpuAIntCommToIntInput = 0x40340523 |
"Spi internal comm has failed chip select synchronisation"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_CpuAIntCommToXInput = 0x40340520 |
"Spi exchange has failed chip select synchronisation"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_CpuAIntCommToXTx = 0x40340521 |
"Spi exchange didn't finish transmitting in time"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_CpuAMgrRpStep = 0x4034054B |
"Wrong value of reporting manager step"
| INOS_MCMSG_FLAG_NONE uint32 INOS_MCTARGET_SAFETY_DEVICE_CpuBDevHwRevInputs = 0x4034050F |
"Wrong value of hardware revision inputs"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_CtrlDevFsTestIncomplete = 0x4034053A |
"Fail-Safe device tests were not completed within 1 hour"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_CtrlDevInpTestIncomplete = 0x40340537 |
"Input device tests were not completed within 1 hour"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_CtrlDevOutTestIncomplete = 0x40340538 |
"Output device tests were not completed within 1 hour"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_CtrlDevStoTestIncomplete = 0x40340539 |
"STO device tests were not completed within 1 hour"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_CtrlFailSafeInitHigh = 0x403405A1 |
"Failsafe device: initial test toggling should not create safe 24V"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_CtrlFailSafeNoDrop = 0x40340598 |
"Failsafe device: safe voltage didn't drop after switching off toggling"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_CtrlFailSafeSkip = 0x40340599 |
"Failsafe device: fail safe test skipped too many times"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_CtrlInputExternal0 = 0x4034058E |
"Input device: external input test has failed on input 0"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_CtrlInputExternal1 = 0x4034058F |
"Input device: external input test has failed on input 1"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_CtrlInputExternal2 = 0x40340590 |
"Input device: external input test has failed on input 2"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_CtrlInputExternal3 = 0x40340591 |
"Input device: external input test has failed on input 3"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_CtrlInputExternalFBHigh = 0x4034058D |
"Input device: pulse output is not low"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_CtrlInputExternalFBLow = 0x403405A7 |
"Input device: pulse output is not high"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_CtrlInputInconsistent0 = 0x40340592 |
"Input device: input dual channels not consistent on input 0"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_CtrlInputInconsistent1 = 0x40340593 |
"Input device: input dual channels not consistent on input 1"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_CtrlInputInconsistent2 = 0x40340594 |
"Input device: input dual channels not consistent on input 2"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_CtrlInputInconsistent3 = 0x40340595 |
"Input device: input dual channels not consistent on input 3"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_CtrlInputInternal = 0x4034058C |
"Input device: internal input test has failed"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_CtrlIntCommInputs = 0x4034052A |
"Input communication frames don't match"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_CtrlMgrImcState = 0x40340548 |
"Wrong value of inter module communication manager state"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_CtrlMoniCommTo = 0x40340534 |
"Communication loss to axis monitor"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_CtrlOutputExternalOffTooHigh = 0x40340597 |
"Output device: external feedback high when output is off"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_CtrlOutputExternalOnTooHigh = 0x403405A6 |
"Output device: external feedback too high for output on"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_CtrlOutputExternalOnTooLow = 0x403405A5 |
"Output device: external feedback low when output is on"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_CtrlOutputExternalPulseIsHigh = 0x403405A3 |
"Output device: external feedback is high during test pulse"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_CtrlOutputInternalOffIsHigh = 0x40340596 |
"Output device: internal feedback high when output is off"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_CtrlOutputInternalOnIsLow = 0x403405A4 |
"Output device: internal feedback high when output is off"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_CtrlOutputInternalPulseIsHigh = 0x403405A2 |
"Output device: internal feedback is high during test pulse"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_CtrlSafe24VCycleTimeTooLarge = 0x4034059B |
"Failsafe device: cycle time between Safe24V checks is too large"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_CtrlSafe24VDiffTooLarge = 0x4034059A |
"Failsafe device: difference between safe voltage and 24V is too large"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_CtrlSafetyStateCycleTimeTooLarge = 0x403405A9 |
"SafetyState manager: cycle time between update confirms too large"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_CtrlSafetyStateTooManyConfirms = 0x403405A8 |
"SafetyState manager: too many confirms"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_CtrlSelectionConfigError = 0x4034054F |
"Configured operation mode selection not supported"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_CtrlStoOffTooHigh = 0x403405A0 |
"Sto device: output voltage while switched off is too high"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_CtrlStoOnTooHigh = 0x4034059D |
"Sto device: output voltage while switched on is too high"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_CtrlStoOnTooLow = 0x4034059C |
"Sto device: output voltage while switched on is too low"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_CtrlStoTestTooHigh = 0x4034059F |
"Sto device: output voltage during test pulse too high"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_CtrlStoTestTooLow = 0x4034059E |
"Sto device: output voltage during test pulse too low"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_CtrlSynchSafetyState = 0x40340514 |
"Safety state on cpu A and B doesn't match"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_eISE_MoniConfigInvalidSignalStrength = 0x40340564 |
"Configured axis signal strength invalid"
| INOS_MCMSG_FLAG_NONE uint32 INOS_MCTARGET_SAFETY_DEVICE_ERROR = 0x40340500 |
"Safety device error"
| uint32 INOS_MCTARGET_SAFETY_DEVICE_MAP_INVALID = 0x40340009 |
"UID to Indel hardware mapping file invalid"
| uint32 INOS_MCTARGET_SAFETY_DEVICE_MAP_MISSING = 0x40340008 |
"UID to Indel hardware mapping file missing"
| uint32 INOS_MCTARGET_SAFETY_DEVICE_MAP_PARSE_FAILED = 0x4034000A |
"Parsing UID to Indel hardware mapping file failed"
| uint32 INOS_MCTARGET_SAFETY_DEVICE_MAP_UID_NOT_FOUND = 0x4034000B |
"Failed to get UID from hardware mapping file"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_MoniAxisMonitoringState = 0x403405C8 |
"Wrong axis monitoring state"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_MoniConfigAxisNumber = 0x40340560 |
"Configured axis number doesn't match hardware axis number"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_MoniConfigInvalidLimit = 0x40340561 |
"Configured axis safety function limit is not valid"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_MoniConfigInvalidSafetyFunction = 0x40340562 |
"Configured axis safety function not valid"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_MoniConfigInvalidTolerance = 0x40340563 |
"Configured axis signal tolerance invalid"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_MoniDevScDma20Enabled = 0x40340529 |
"Spi dma 2 stream 0 couldn't be disabled in time"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_MoniDevScInit = 0x4034054D |
"Error in initialisation of sincos device"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_MoniDevScNonexQuad = 0x4034054E |
"Error in encoder quadrant and sincos alignment, non-existing quadrant"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_MoniDevScTestIncomplete = 0x4034053B |
"SinCos device tests were not completed within 1 hour"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_MoniFeedbackOffsetDiffTooLarge = 0x403405C3 |
"Feedback voltage offset difference between CPU A and CPU B too large"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_MoniFeedbackOffsetTooHigh = 0x403405C1 |
"Feedback voltage offset too high"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_MoniFeedbackOffsetTooLow = 0x403405C2 |
"Feedback voltage offset too low"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_MoniMgrAmSafetyLevel = 0x40340546 |
"Requested safety level from configuration higher than supported"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_MoniPosPosDiffTooLarge = 0x403405BE |
"Difference in position between CPU A and B is too large"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_MoniPosS2C2DiffTooLarge = 0x403405BF |
"Difference in sin^2 + cos^2 between CPU A and B is too large"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_MoniPosSpeedDiffTooLarge = 0x403405BD |
"Difference in speed between CPU A and B is too large"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_MoniResNonPosTimeDiff = 0x40340551 |
"Resolver speed calculation time was not a positive number"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_MoniResolverInconsistency = 0x403405B4 |
"Resolver device: could not read consistent ADC values in time"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_MoniResolverPosNegAmpl = 0x403405C6 |
"Difference between positive and negative amplitude too large"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_MoniResolverS2C2TooHigh = 0x403405B7 |
"Resolver device: sin^2 + cos^2 is too high"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_MoniResolverS2C2TooLow = 0x403405B6 |
"Resolver device: sin^2 + cos^2 is too low"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_MoniResolverTriggerMissing = 0x403405B5 |
"Resolver device: no trigger received in time"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_MoniResSpeedFilterSize = 0x40340550 |
"Resolver speed filter size error"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_MoniSafetyLevelInconsistency = 0x403405C7 |
"Inconsistency in safety level between CPU A and CPU B"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_MoniSinCosAccelDiffTooLarge = 0x403405C5 |
"Difference in acceleration between CPU A and CPU B too large"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_MoniSinCosAccelerationTooLarge = 0x403405C4 |
"Feedback acceleration too large"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_MoniSinCosAlignment = 0x403405BB |
"SinCos device: encoder and sincos angles are not in the same sector"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_MoniSinCosEncoderStep = 0x403405BC |
"SinCos device: encoder step larger than one"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_MoniSinCosS2C2TooHigh = 0x403405B9 |
"SinCos device: sin^2 + cos^2 is too high"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_MoniSinCosS2C2TooLow = 0x403405B8 |
"SinCos device: sin^2 + cos^2 is too low"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_DEVICE_MoniSinCosS2C2TooLowSpeed = 0x403405BA |
"SinCos device: sin^2 + cos^2 is too low at high speed"
| uint32 INOS_MCTARGET_SAFETY_DEVICE_NO_RAM = 0x40340015 |
"No communication RAM to safety device detected"
| uint32 INOS_MCTARGET_SAFETY_GENERAL = 0x40340001 |
"General error"
| uint32 INOS_MCTARGET_SAFETY_INCOV_PASSWORD_MISSING = 0x40340014 |
"ch.indel.data.system incov.password missing (mandatory for safety applications)"
| uint32 INOS_MCTARGET_SAFETY_NO_DEVICE = 0x4034000C |
"No safety device detected"
| INOS_MCMSG_FLAG_NONE uint32 INOS_MCTARGET_SAFETY_RESET_FAILED = 0x40340200 |
"Reset failed, please reboot!"
| INOS_MCMSG_FLAG_NONE uint32 INOS_MCTARGET_SAFETY_RESET_READ08_FAILED = 0x40340201 |
"Reset failed due to a read uint8 failure, please reboot!"
| INOS_MCMSG_FLAG_NONE uint32 INOS_MCTARGET_SAFETY_RESET_READ16_FAILED = 0x40340203 |
"Reset failed due to a read uint16 failure, please reboot!"
| INOS_MCMSG_FLAG_NONE uint32 INOS_MCTARGET_SAFETY_RESET_READ32_FAILED = 0x40340205 |
"Reset failed due to a read uint32 failure, please reboot!"
| INOS_MCMSG_FLAG_NONE uint32 INOS_MCTARGET_SAFETY_RESET_TIMEOUT_FAILED = 0x40340210 |
"Reset failed, no reaction from safety device, please reboot!"
| INOS_MCMSG_FLAG_NONE uint32 INOS_MCTARGET_SAFETY_RESET_WRITE08_FAILED = 0x40340202 |
"Reset failed due to a write uint8 failure, please reboot!"
| INOS_MCMSG_FLAG_NONE uint32 INOS_MCTARGET_SAFETY_RESET_WRITE16_FAILED = 0x40340204 |
"Reset failed due to a write uint16 failure, please reboot!"
| INOS_MCMSG_FLAG_NONE uint32 INOS_MCTARGET_SAFETY_RESET_WRITE32_FAILED = 0x40340206 |
"Reset failed due to a write uint32 failure, please reboot!"
| INOS_MCMSG_FLAG_NONE uint32 INOS_MCTARGET_SAFETY_SETUP_FAILED = 0x40340300 |
"Setting up configuration failed, please reboot"
| INOS_MCMSG_FLAG_NONE uint32 INOS_MCTARGET_SAFETY_SETUP_NEEDS_VERIFICATION = 0x40340320 |
"Safety configuration needs verification"
| INOS_MCMSG_FLAG_NONE uint32 INOS_MCTARGET_SAFETY_SETUP_READ08_FAILED = 0x40340301 |
"Setting up configuration failed due to a read uint8 failure, please reboot!"
| INOS_MCMSG_FLAG_NONE uint32 INOS_MCTARGET_SAFETY_SETUP_READ16_FAILED = 0x40340303 |
"Setting up configuration failed due to a read uint16 failure, please reboot!"
| INOS_MCMSG_FLAG_NONE uint32 INOS_MCTARGET_SAFETY_SETUP_READ32_FAILED = 0x40340305 |
"Setting up configuration failed due to a read uint32 failure, please reboot!"
| INOS_MCMSG_FLAG_NONE uint32 INOS_MCTARGET_SAFETY_SETUP_TIMEOUT_FAILED = 0x40340310 |
"Setting up configuration failed, no reaction from safety device, please reboot!"
| INOS_MCMSG_FLAG_NONE uint32 INOS_MCTARGET_SAFETY_SETUP_WRITE08_FAILED = 0x40340302 |
"Setting up configuration failed due to a write uint8 failure, please reboot!"
| INOS_MCMSG_FLAG_NONE uint32 INOS_MCTARGET_SAFETY_SETUP_WRITE16_FAILED = 0x40340304 |
"Setting up configuration failed due to a write uint16 failure, please reboot!"
| INOS_MCMSG_FLAG_NONE uint32 INOS_MCTARGET_SAFETY_SETUP_WRITE32_FAILED = 0x40340306 |
"Setting up configuration failed due to a write uint32 failure, please reboot!"
| INOS_MCMSG_FLAG_NONE uint32 INOS_MCTARGET_SAFETY_SETUP_WRITE_FAILED = 0x40340307 |
"Setting up configuration failed due to a write to safety ram failure, please reboot and contact Indel"
| INOS_MCMSG_FLAG_SAFETY_RESET uint32 INOS_MCTARGET_SAFETY_STO = 0x40340600 |
"Safe torque off (STO) : unknown"
| uint32 INOS_MCTARGET_SAFETY_STO_24H_AXIS0 = 0x4034060B |
"Axis was not moved for 24 hours (STO) : axis number 0"
| uint32 INOS_MCTARGET_SAFETY_STO_24H_AXIS1 = 0x4034060C |
"Axis was not moved for 24 hours (STO) : axis number 1"
| uint32 INOS_MCTARGET_SAFETY_STO_24H_AXIS2 = 0x4034060D |
"Axis was not moved for 24 hours (STO) : axis number 2"
| uint32 INOS_MCTARGET_SAFETY_STO_24H_AXIS3 = 0x4034060E |
"Axis was not moved for 24 hours (STO) : axis number 3"
| uint32 INOS_MCTARGET_SAFETY_STO_AXIS0 = 0x40340603 |
"Safe torque off (STO) : axis number 0"
| uint32 INOS_MCTARGET_SAFETY_STO_AXIS1 = 0x40340604 |
"Safe torque off (STO) : axis number 1"
| uint32 INOS_MCTARGET_SAFETY_STO_AXIS2 = 0x40340605 |
"Safe torque off (STO) : axis number 2"
| uint32 INOS_MCTARGET_SAFETY_STO_AXIS3 = 0x40340606 |
"Safe torque off (STO) : axis number 3"
| uint32 INOS_MCTARGET_SAFETY_STO_INPUT_LOW = 0x40340601 |
"Safe torque off (STO) : STO input low"
| uint32 INOS_MCTARGET_SAFETY_STO_NMD_AXIS0 = 0x40340607 |
"Axis was never moved (STO) : axis number 0"
| uint32 INOS_MCTARGET_SAFETY_STO_NMD_AXIS1 = 0x40340608 |
"Axis was never moved (STO) : axis number 1"
| uint32 INOS_MCTARGET_SAFETY_STO_NMD_AXIS2 = 0x40340609 |
"Axis was never moved (STO) : axis number 2"
| uint32 INOS_MCTARGET_SAFETY_STO_NMD_AXIS3 = 0x4034060A |
"Axis was never moved (STO) : axis number 3"
| uint32 INOS_MCTARGET_SAFETY_STO_RING_INPUT_LOW = 0x40340602 |
"Safe torque off (STO) : ring input low"
| uint32 INOS_MCTARGET_SAFETY_UNKNOWN_DEVICE_ID = 0x40340005 |
"Unknown device id given"
| uint32 INOS_MCTARGET_SAFETY_UNKNOWN_DEVICE_NAME = 0x40340007 |
"Unknown device name given"
| uint32 INOS_MCTARGET_SAFETY_UNKNOWN_MAIN_DEVICE_ID = 0x40340006 |
"Unknown main device id given"
| uint32 INOS_MCTARGET_SAFETY_UNKNOWN_MONITOR_DEVICE0 = 0x40340010 |
"Unknown monitor device 0 requested"
| uint32 INOS_MCTARGET_SAFETY_UNKNOWN_MONITOR_DEVICE1 = 0x40340011 |
"Unknown monitor device 1 requested"
| uint32 INOS_MCTARGET_SAFETY_UNKNOWN_MONITOR_DEVICE2 = 0x40340012 |
"Unknown monitor device 2 requested"
| uint32 INOS_MCTARGET_SAFETY_UNKNOWN_MONITOR_DEVICE3 = 0x40340013 |
"Unknown monitor device 3 requested"
| INOS_MCMSG_FLAG_NONE uint32 INOS_MCTARGET_SAFETY_VERIFY_INVALID_REPLY = 0x40340430 |
"Verifying configuration failed, invalid reply from user"
| INOS_MCMSG_FLAG_NONE uint32 INOS_MCTARGET_SAFETY_VERIFY_READ08_FAILED = 0x40340401 |
"Verifying configuration failed due to a read uint8 failure, please reboot!"
| INOS_MCMSG_FLAG_NONE uint32 INOS_MCTARGET_SAFETY_VERIFY_READ16_FAILED = 0x40340403 |
"Verifying configuration failed due to a read uint16 failure, please reboot!"
| INOS_MCMSG_FLAG_NONE uint32 INOS_MCTARGET_SAFETY_VERIFY_READ32_FAILED = 0x40340405 |
"Verifying configuration failed due to a read uint32 failure, please reboot!"
| INOS_MCMSG_FLAG_NONE uint32 INOS_MCTARGET_SAFETY_VERIFY_TIMEOUT_FAILED = 0x40340410 |
"Verifying configuration failed, no reaction from safety device, please reboot!"
| INOS_MCMSG_FLAG_NONE uint32 INOS_MCTARGET_SAFETY_VERIFY_WRITE08_FAILED = 0x40340402 |
"Verifying configuration failed due to a write uint8 failure, please reboot!"
| INOS_MCMSG_FLAG_NONE uint32 INOS_MCTARGET_SAFETY_VERIFY_WRITE16_FAILED = 0x40340404 |
"Verifying configuration failed due to a write uint16 failure, please reboot!"
| INOS_MCMSG_FLAG_NONE uint32 INOS_MCTARGET_SAFETY_VERIFY_WRITE32_FAILED = 0x40340406 |
"Verifying configuration failed due to a write uint32 failure, please reboot!"
| uint32 INOS_MCTARGET_SHUTDOWN_NOT_SUPPORTED = 0x40300005 |
"Shutdown not supported"
| uint32 INOS_MCTARGET_SHUTDOWN_PARAM_INVALID = 0x40300006 |
"Invalid shutdown param detected"
| uint32 INOS_MCTARGET_SHUTDOWN_PARAM_UNKNOWN = 0x40300007 |
"Unknown shutdown param requested"
| uint32 INOS_MCTARGET_SHUTDOWN_TYPE_FORCE_NOT_SUPPORTED = 0x40300009 |
"Shutdown type 'force' not supported"
| uint32 INOS_MCTARGET_SHUTDOWN_TYPE_UNKNOWN = 0x40300008 |
"Unknown shutdown type requested"
| uint32 INOS_MCTARGET_SUBSCRIPTION_ID_UNKNOWN = 0x40300002 |
"Unknown subscription id given"
| uint32 INOS_MCTARGET_SUBSCRIPTION_NOT_ALLOWED = 0x40300001 |
"Subscription only from CINOSMcTargetResource based classes allowed"
| uint32 INOS_MCTARGET_SUPERVISION_COOLING_WARNING = 0x403F4004 |
"Cooling system warning"
| uint32 INOS_MCTARGET_SUPERVISION_GENERAL = 0x403F4001 |
"General error"
| uint32 INOS_MCTARGET_SUPERVISION_TEMPERATURE_ERROR = 0x403F4003 |
"Overtemperature detected. Danger of hardware damage!"
| uint32 INOS_MCTARGET_SUPERVISION_TEMPERATURE_WARNING = 0x403F4002 |
"Temperature warning"
| uint32 INOS_MCTARGET_SYSTEM_ALREAD_EXISTS = 0x40380005 |
"Variable already exists"
| uint32 INOS_MCTARGET_SYSTEM_FLASH_LOCK_FAILED = 0x4038000B |
"Failed to lock environment flash"
| uint32 INOS_MCTARGET_SYSTEM_FLASH_NOT_FOUND = 0x40380009 |
"System variable device not found"
| uint32 INOS_MCTARGET_SYSTEM_FLASH_UNLOCK_FAILED = 0x4038000A |
"Failed to unlock environment flash"
| uint32 INOS_MCTARGET_SYSTEM_GENERAL = 0x40380001 |
"General error"
| uint32 INOS_MCTARGET_SYSTEM_INVALID_VARIABLE_NAME = 0x40380004 |
"Invalid variable name given"
| uint32 INOS_MCTARGET_SYSTEM_NO_PASSWORD = 0x4038000E |
"No passowrd given"
| uint32 INOS_MCTARGET_SYSTEM_NOT_PROTECTED = 0x4038000D |
"Variable not protected"
| uint32 INOS_MCTARGET_SYSTEM_PASSWORD_TOO_SHORT = 0x4038000F |
"Password too short"
| uint32 INOS_MCTARGET_SYSTEM_PERSISTENT_IMAGE_CREATION_FAILED = 0x40380007 |
"Persistent image creation failed"
| uint32 INOS_MCTARGET_SYSTEM_PERSISTENT_IMAGE_TO_BIG = 0x40380008 |
"Persistent image too big"
| uint32 INOS_MCTARGET_SYSTEM_PERSISTENT_NOT_SUPPORTED = 0x40380006 |
"Persistent write not supported"
| uint32 INOS_MCTARGET_SYSTEM_PROTECTED = 0x4038000C |
"Variable protected, unprotect first"
| uint32 INOS_MCTARGET_SYSTEM_UNKNOWN_CONTAINER = 0x40380002 |
"Unknown container"
| uint32 INOS_MCTARGET_SYSTEM_UNKNOWN_VARIABLE = 0x40380003 |
"Unknown variable"
| uint32 INOS_MCTARGET_SYSTEM_WRONG_PASSWORD = 0x40380010 |
"Wrong password given"
| uint32 INOS_MCTARGET_TEST_NVRAM_BACKUP_ALREADY_EXISTS = 0x40390002 |
"Backup already exists"
| uint32 INOS_MCTARGET_TEST_NVRAM_BACKUP_UNKNOWN = 0x40390003 |
"Unknown backup"
| uint32 INOS_MCTARGET_TEST_NVRAM_GENERAL = 0x40390001 |
"General error"
| uint32 INOS_MCTARGET_TEST_NVRAM_TEST_CORRUPTED_BLOCK = 0x40390007 |
"Corrupted NVRAM block detected"
| uint32 INOS_MCTARGET_TEST_NVRAM_TEST_NO_RUNNING = 0x40390006 |
"No test running"
| uint32 INOS_MCTARGET_TEST_NVRAM_TEST_ONLY_ONE = 0x40390005 |
"Only one running test allowed"
| uint32 INOS_MCTARGET_TEST_NVRAM_TEST_UNKNOWN = 0x40390004 |
"Unknown test requested, currently only 'mcrobot' allowed"
| uint32 INOS_MCTARGET_TEST_RAM_GENERAL = 0x40391001 |
"General error"
| uint32 INOS_MCTARGET_TEST_RAM_TEST_CORRUPTED_CODE = 0x40391005 |
"Corrupted code detected"
| uint32 INOS_MCTARGET_TEST_RAM_TEST_NO_RUNNING = 0x40391004 |
"No test running"
| uint32 INOS_MCTARGET_TEST_RAM_TEST_ONLY_ONE = 0x40391003 |
"Only one running test allowed"
| uint32 INOS_MCTARGET_TEST_RAM_TEST_READ_FAILURE = 0x40391007 |
"Reading from RAM failed"
| uint32 INOS_MCTARGET_TEST_RAM_TEST_UNKNOWN = 0x40391002 |
"Unknown test requested, currently only 'general' allowed"
| uint32 INOS_MCTARGET_TEST_RAM_TEST_WRITE_FAILURE = 0x40391006 |
"Writing to RAM failed"
| uint32 INOS_MDNS_NAME_CONFLICT = 0x408A0001 |
"mDNS name conflict"
| uint32 INOS_MOVEPATH_ERROR_ASCENDING_AXIS_INDEX = 0x4014000D |
"Ascending axis index required"
| uint32 INOS_MOVEPATH_ERROR_ASYNCH_NOT_ALLOWED = 0x40140016 |
"Asynchronous call not allowed, no helper available"
| uint32 INOS_MOVEPATH_ERROR_ASYNCH_NOT_ALLOWED_FOR_CMD = 0x40140036 |
"Asynchronous call not allowed for this command"
| uint32 INOS_MOVEPATH_ERROR_AXIS_INDEX_USED_TWICE = 0x40140014 |
"Axis index used twice"
| uint32 INOS_MOVEPATH_ERROR_COMMAND_CANCELED = 0x40140002 |
"Command canceled"
| uint32 INOS_MOVEPATH_ERROR_COMMAND_NOT_YET_IMPLEMENTED = 0x40140034 |
"Command not yet implemented"
| uint32 INOS_MOVEPATH_ERROR_COMMAND_REJECTED_ERROR = 0x40140004 |
"Command rejected, path is on error"
| uint32 INOS_MOVEPATH_ERROR_COMMAND_REJECTED_WRONG_STATE = 0x40140003 |
"Command rejected, path in wrong state"
| uint32 INOS_MOVEPATH_ERROR_COMMAND_UNKNOWN = 0x40140001 |
"Unknown movepath command"
| uint32 INOS_MOVEPATH_ERROR_CRV_ABSOLUTE_WRONG_START = 0x40141002 |
"Absolute curve has wrong start vector"
| uint32 INOS_MOVEPATH_ERROR_CRV_GENERAL = 0x40141000 |
"General movepath curve error"
| uint32 INOS_MOVEPATH_ERROR_CRV_RELOCATE_WITH_START = 0x40141001 |
"Relocatable curve with start vector not allowed"
| uint32 INOS_MOVEPATH_ERROR_CYCLETIME_NO_AXIS_SET = 0x4014001C |
"Cycletime not available, no axis set"
| uint32 INOS_MOVEPATH_ERROR_DELEGATE_NOT_ALLOWED = 0x4014001B |
"Delegate not allowed if asynch support activated"
| uint32 INOS_MOVEPATH_ERROR_DUPLICATE_NAME = 0x40140032 |
"Duplicate movepath name detected"
| uint32 INOS_MOVEPATH_ERROR_EDITBEGIN_NOT_ALLOWED = 0x4014003D |
"EditBegin not allowed, EditEnd missing"
| uint32 INOS_MOVEPATH_ERROR_EVENT_DUPLICATE_NAME = 0x40140020 |
"Duplicate event name detected"
| uint32 INOS_MOVEPATH_ERROR_EVENT_DUPLICATE_PRESTART = 0x40140024 |
"Only one prestart event allowed (Type=eEvtBgnMs and Time<0)"
| uint32 INOS_MOVEPATH_ERROR_EVENT_INVALID_RECEIVER_TYPE = 0x40140022 |
"Receiver needs to be of type CINOSTaskEx or descendant"
| uint32 INOS_MOVEPATH_ERROR_EVENT_INVALID_TYPE = 0x4014001F |
"Invalid event type requested"
| uint32 INOS_MOVEPATH_ERROR_EVENT_NEAGTIVE_NOT_ALLOWED = 0x40140025 |
"Negative value not allowed for this event type"
| uint32 INOS_MOVEPATH_ERROR_EVENT_TICKS_NOT_YET_AVAILABLE = 0x4014001E |
"Event ticks not yet available"
| uint32 INOS_MOVEPATH_ERROR_EVENT_UNKNOWN_RECEIVER = 0x40140021 |
"Unknown event receiver"
| uint32 INOS_MOVEPATH_ERROR_GENERAL = 0x40140000 |
"General movepath error"
| uint32 INOS_MOVEPATH_ERROR_HELPER_NO_VALID_PATH = 0x40140018 |
"Helper got command without a valid path"
| uint32 INOS_MOVEPATH_ERROR_INVALID_AXIS_INDEX = 0x4014000C |
"Invalid axis index requested"
| uint32 INOS_MOVEPATH_ERROR_INVALID_JSON_PARAM_GIVEN = 0x40140035 |
"Invalid JSON param given"
| uint32 INOS_MOVEPATH_ERROR_INVALID_POINTER = 0x40140005 |
"Ivalid pointer given"
| uint32 INOS_MOVEPATH_ERROR_INVALID_RESOURCE_INDEX = 0x40140044 |
"Invalid resource index requested"
| uint32 INOS_MOVEPATH_ERROR_INVALID_SPEEDSET = 0x40140048 |
"Invalid speedset Values"
| uint32 INOS_MOVEPATH_ERROR_INVALID_TOLERANCE = 0x40140010 |
"Invalid tolerance given"
| uint32 INOS_MOVEPATH_ERROR_INVALID_VELOCITY = 0x40140011 |
"Invalid velocity given"
| uint32 INOS_MOVEPATH_ERROR_ITP_FIRST_NEEDS_TO_BE_LINEAR = 0x40142009 |
"First curve segment needs to be pure linear"
| uint32 INOS_MOVEPATH_ERROR_ITP_GENERAL = 0x40142000 |
"General movepath interpolator error"
| uint32 INOS_MOVEPATH_ERROR_ITP_INVALID_ONSHRINK_PARAMETER = 0x4014200D |
"Shape interpolator detected an invalid 'Shape.OnShrink' parameter value"
| uint32 INOS_MOVEPATH_ERROR_ITP_LAST_NEEDS_TO_BE_LINEAR = 0x4014200A |
"Last curve segment needs to be pure linear"
| uint32 INOS_MOVEPATH_ERROR_ITP_MAX_SEGMENTS = 0x40142002 |
"Max. number of supported segments reached"
| uint32 INOS_MOVEPATH_ERROR_ITP_NO_RESULT = 0x40142006 |
"Interpolator failed to handle given curve"
| uint32 INOS_MOVEPATH_ERROR_ITP_ONLY_2DIM = 0x40142007 |
"Interpolator allows only two dimensional curves"
| uint32 INOS_MOVEPATH_ERROR_ITP_ONLY_INDEX0_AND_1 = 0x40142008 |
"Interpolator allows only axis index 0 and 1"
| uint32 INOS_MOVEPATH_ERROR_ITP_ONLY_LINEAR_SEGMENTS = 0x40142003 |
"Interpolator supports only linear segments"
| uint32 INOS_MOVEPATH_ERROR_ITP_OVERLAP_NEGATIVE = 0x4014200E |
"'Nurrbs.Overlap' < 0.0 is not allowed"
| uint32 INOS_MOVEPATH_ERROR_ITP_OVERLAP_TOO_BIG = 0x4014200F |
"'Nurbs.Overlap' can't be bigger than a thrid of 'Nurbs.MaxLength'"
| uint32 INOS_MOVEPATH_ERROR_ITP_PARAM_MISSING = 0x40142005 |
"Interpolator parameters missing"
| uint32 INOS_MOVEPATH_ERROR_ITP_SEGMENT_TYPE_NOT_SUPPORTED = 0x40142004 |
"Segment type not supported by requested interpolator"
| uint32 INOS_MOVEPATH_ERROR_ITP_STOP_REQUESTED_BUT_NOT_SUPPORTED = 0x4014200C |
"Interpolator requires stop but trajectory doesn't support it"
| uint32 INOS_MOVEPATH_ERROR_ITP_TRANSITION_SHRINK = 0x40142001 |
"Transition segment needs to be shrunk"
| uint32 INOS_MOVEPATH_ERROR_ITP_TWO_NON_LINEAR = 0x4014200B |
"Two successive non linear segments are not allowed"
| uint32 INOS_MOVEPATH_ERROR_MAINAXIS_INDEX_INVALID = 0x40140023 |
"Invalid main axis index given"
| uint32 INOS_MOVEPATH_ERROR_MAPPING_WRONG_DIMENSION = 0x4014001D |
"Mapping has wrong dimension"
| uint32 INOS_MOVEPATH_ERROR_MAX_HELPER = 0x40140017 |
"Max. number of supported helpers reached"
| uint32 INOS_MOVEPATH_ERROR_NO_APPEND_CURVE = 0x40140040 |
"No curve to append available"
| uint32 INOS_MOVEPATH_ERROR_NO_AXIS_SET = 0x4014000F |
"No axis set"
| uint32 INOS_MOVEPATH_ERROR_NO_COMMAND_QUEUE = 0x40140019 |
"No command queue available"
| uint32 INOS_MOVEPATH_ERROR_NO_EDIT_CURVE = 0x4014003C |
"No edit curve available, EditBegin missing"
| uint32 INOS_MOVEPATH_ERROR_NO_PREPARE_CURVE = 0x4014003E |
"No curve to prepare available"
| uint32 INOS_MOVEPATH_ERROR_NO_RUN_CURVE = 0x4014003F |
"No prepared curve available"
| uint32 INOS_MOVEPATH_ERROR_NURBS_ALL_WEIGHTS_ZERO = 0x40140030 |
"Nurbs with all control point weights = 0.0"
| uint32 INOS_MOVEPATH_ERROR_NURBS_DEGREE_INVALID = 0x4014002D |
"Invalid nurbs curve degree selected (allowed 1..3)"
| uint32 INOS_MOVEPATH_ERROR_NURBS_NOT_ENOUGH_POINTS = 0x4014002E |
"Nurbs curve does not have enough points (needs at least degree+1)"
| uint32 INOS_MOVEPATH_ERROR_NURBS_NRBBEGIN_MISSING = 0x4014002B |
"NrbBegin missing"
| uint32 INOS_MOVEPATH_ERROR_NURBS_NRBEND_MISSING = 0x4014002C |
"NrbEnd missing"
| uint32 INOS_MOVEPATH_ERROR_NURBS_NRBPOINT_AXES = 0x40140031 |
"NrbPoint got invalid number of coordinates"
| uint32 INOS_MOVEPATH_ERROR_NURBS_NUMBER_OF_KNOTS_INVALID = 0x4014002F |
"Nurbs with wrong number of knots (needs points+degree+1)"
| uint32 INOS_MOVEPATH_ERROR_NURBS_RELEVANT_LENGTH_ZERO = 0x40140037 |
"Nurbs curve relevant length must be non-zero at any point of the curve "
| uint32 INOS_MOVEPATH_ERROR_NURBS_REQUIRES_INTERPOLATOR_NONE = 0x40140026 |
"Curve type 'Nurbs' requires interpolator type 'None'"
| uint32 INOS_MOVEPATH_ERROR_NURBS_SEGBEGIN_NOT_ALLOWED = 0x40140027 |
"SegBegin not allowed, use NrbBegin instead"
| uint32 INOS_MOVEPATH_ERROR_NURBS_SEGEND_NOT_ALLOWED = 0x40140028 |
"SegEnd not allowed, use NrbEnd instead"
| uint32 INOS_MOVEPATH_ERROR_OPTION_ASYNCH = 0x40140008 |
"Asynchronous support disabled"
| uint32 INOS_MOVEPATH_ERROR_OPTION_EXCEPTION = 0x40140007 |
"Exception support disabled"
| uint32 INOS_MOVEPATH_ERROR_OPTION_INVALID = 0x40140006 |
"Invalid movepath option requested"
| uint32 INOS_MOVEPATH_ERROR_PARAM_NOT_FOUND = 0x40140015 |
"Requested param not found"
| uint32 INOS_MOVEPATH_ERROR_RAPID_RAMP_CALC = 0x40140047 |
"Rapid part ramp calculation failed"
| uint32 INOS_MOVEPATH_ERROR_RAPIDBEGIN_MISSING = 0x40140039 |
"RapidBegin missing"
| uint32 INOS_MOVEPATH_ERROR_RAPIDEND_MISSING = 0x4014003A |
"RapidEnd missing"
| uint32 INOS_MOVEPATH_ERROR_SEGBEGIN_MISSING = 0x40140012 |
"SegBegin missing"
| uint32 INOS_MOVEPATH_ERROR_SEGEND_MISSING = 0x40140013 |
"SegEnd missing"
| uint32 INOS_MOVEPATH_ERROR_SETCURVE_NOT_ALLOWED = 0x40140046 |
"SetCurve not allowed when there is already a curve"
| uint32 INOS_MOVEPATH_ERROR_TO_MANY_AXES = 0x40140041 |
"Too many axes added, maximal number of supported axes reached"
| uint32 INOS_MOVEPATH_ERROR_TRJ_AXIS_ON_ERROR = 0x40143007 |
"Involved movepath axis on error"
| uint32 INOS_MOVEPATH_ERROR_TRJ_BACK_PLANNING_NOT_YET_SUPPORTED = 0x4014300A |
"Trajectory back planning not yet supported"
| uint32 INOS_MOVEPATH_ERROR_TRJ_BUFFER_NOT_VALID = 0x40143006 |
"Trajectory buffer contains no valid data"
| uint32 INOS_MOVEPATH_ERROR_TRJ_BUFFER_TO_SMALL = 0x40143005 |
"Trajectory buffer too small"
| uint32 INOS_MOVEPATH_ERROR_TRJ_BUFFER_UNDERFLOW = 0x40143010 |
"Trajectory buffer underflow"
| uint32 INOS_MOVEPATH_ERROR_TRJ_CURVE_NOT_1LEVEL_CONT = 0x4014300D |
"Curve is not first level continuous"
| uint32 INOS_MOVEPATH_ERROR_TRJ_CURVE_NOT_2LEVEL_CONT = 0x4014300E |
"Curve is not second level continuous"
| uint32 INOS_MOVEPATH_ERROR_TRJ_GENERAL = 0x40143000 |
"General movepath trajectory error"
| uint32 INOS_MOVEPATH_ERROR_TRJ_MAX_SEGMENTS = 0x40143009 |
"Max. number of supported segments reached"
| uint32 INOS_MOVEPATH_ERROR_TRJ_MOVETIME_DELTA_NOT_SUPPORTED = 0x4014300F |
"Movetime delta != 0.0 not supported"
| uint32 INOS_MOVEPATH_ERROR_TRJ_NOT_AVAILABLE = 0x40143002 |
"Result currently not available"
| uint32 INOS_MOVEPATH_ERROR_TRJ_NOT_SUPPORTED = 0x40143001 |
"Command not supported"
| uint32 INOS_MOVEPATH_ERROR_TRJ_PLANING_FAILED = 0x4014300B |
"Trajectory planning failed with no solution (please report to Indel)"
| uint32 INOS_MOVEPATH_ERROR_TRJ_SEGMENT_TYPE_NOT_YET_SUPPORTED = 0x40143008 |
"Interpolator segment type not yet supported"
| uint32 INOS_MOVEPATH_ERROR_TRJ_UNKNOWN_BUFFER_TYPE = 0x40143003 |
"Unknown trajectory buffer type"
| uint32 INOS_MOVEPATH_ERROR_TRJ_UNKNOWN_SPEEDSET = 0x40143004 |
"Unknown trajectory speedset"
| uint32 INOS_MOVEPATH_ERROR_TRJ_VELOCITY_CHECK = 0x4014300C |
"Requested trajectory velocity too big"
| uint32 INOS_MOVEPATH_ERROR_UNKNOWN_AXIS = 0x4014000E |
"Unknown axis requested"
| uint32 INOS_MOVEPATH_ERROR_UNKNOWN_AXIS_SPEEDSET = 0x4014003B |
"Unknown axis speedset"
| uint32 INOS_MOVEPATH_ERROR_UNKNOWN_AXIS_TYPE = 0x40140038 |
"Unknown axis resource type"
| uint32 INOS_MOVEPATH_ERROR_UNKNOWN_CURVE_TYPE = 0x40140009 |
"Unknown curve type requested"
| uint32 INOS_MOVEPATH_ERROR_UNKNOWN_INTERPOLATOR_TYPE = 0x4014000A |
"Unknown interpolator type requested"
| uint32 INOS_MOVEPATH_ERROR_UNKNOWN_NAME = 0x40140033 |
"Unknown movepath name given"
| uint32 INOS_MOVEPATH_ERROR_UNKNOWN_RESOURCE = 0x40140043 |
"Unknown additional resource requested"
| uint32 INOS_MOVEPATH_ERROR_UNKNOWN_RESOURCE_TYPE = 0x40140042 |
"Unknown additional resource type"
| uint32 INOS_MOVEPATH_ERROR_UNKNOWN_TRAJECTORY_TYPE = 0x4014000B |
"Unknown trajectory type requested"
| uint32 INOS_MOVEPATH_ERROR_WRONG_START_POSITION = 0x4014001A |
"Wrong startposition, can't run path"
| uint32 INOS_MOVEPATH_RESULT_PARSE_INCOPMPLETE = 0x40140045 |
"Parser reached maximum number of segments."
| uint32 INOS_OK = 0x00000000 |
"No error"
| uint32 INOS_OPCUA_CLIENT_CERT_MISSING = 0x4089000A |
"OPC UA client security certificate missing"
| uint32 INOS_OPCUA_CLIENT_DISCONNECTED = 0x40890006 |
"OPC UA client disconnected"
| uint32 INOS_OPCUA_CLIENT_INTERNAL = 0x40890000 |
"An internal open62541 library error occurred. Check Eventlog or GetInternalStatus() for details"
| uint32 INOS_OPCUA_CLIENT_METHOD_PARAM_TYPE_MISMATCH = 0x40890003 |
"Parameter type mismatch in OPC UA method call"
| uint32 INOS_OPCUA_CLIENT_MISSING_CREDENTIALS = 0x4089000D |
"OPC UA client missing username and/or password"
| uint32 INOS_OPCUA_CLIENT_NODEID_UNKNOWN = 0x40890001 |
"OPC UA node id unknown"
| uint32 INOS_OPCUA_CLIENT_PRIVKEY_MISSING = 0x4089000B |
"OPC UA client private key missing"
| uint32 INOS_OPCUA_CLIENT_SECURITY_CONFIG_MISSING = 0x40890009 |
"OPC UA client security configuration missing"
| uint32 INOS_OPCUA_CLIENT_SECURITY_NOT_AVAILABLE = 0x40890007 |
"OPC UA security support not available. Please check iDev features"
| uint32 INOS_OPCUA_CLIENT_SERVERCERT_MISSING = 0x4089000C |
"OPC UA client trust list certificate not found"
| uint32 INOS_OPCUA_CLIENT_STRING_BUFFER_TOO_SMALL = 0x40890004 |
"Provided string buffer is too small in OPC UA call"
| uint32 INOS_OPCUA_CLIENT_TOO_MANY_ARGUMENTS = 0x40890005 |
"Too many (input) arguments in OPC UA call"
| uint32 INOS_OPCUA_CLIENT_URI_MISSING = 0x40890008 |
"OPC UA client application URI must be specified"
| uint32 INOS_OPCUA_CLIENT_VALUE_TYPE_MISMATCH = 0x40890002 |
"Value type mismatch in OPC UA call"
| uint32 INOS_OUTPWM_NAME_UNKNOWN = 0x408D0005 |
"Unknown output pwm name given."
| uint32 INOS_OUTPWM_POWER_DETECTION_DISABLED = 0x408D0000 |
"Power frequency detection disabled."
| uint32 INOS_OUTPWM_POWER_DETECTION_FAILED = 0x408D0003 |
"Power frequency detection failed."
| uint32 INOS_OUTPWM_POWER_DETECTION_ON_GOING = 0x408D0002 |
"Power frequency detection on going."
| uint32 INOS_OUTPWM_POWER_DETECTION_STATE_UNKNOWN = 0x408D0004 |
"Power frequency detection ended in an unknown state."
| uint32 INOS_OUTPWM_POWER_DETECTION_WAITING_SYNC = 0x408D0001 |
"Waiting for power sync input."
| uint32 INOS_OUTPWM_POWER_FREQUENCY_INVALID = 0x408D0006 |
"Invalid power frequency given."
| uint32 INOS_SAFECONFIG_HEADER_INVALID_MAGIC_NUMBER = 0x40850001 |
"Safe config has invalid magic number"
| uint32 INOS_SAFECONFIG_HEADER_MAX_DEVICES = 0x40850002 |
"Safe config has invalid number of devices"
| uint32 INOS_SAFECONFIG_HEADER_NO_DEVICES = 0x40850003 |
"Safe config has no devices"
| uint32 INOS_SAFECONFIG_UNKNOWN_INDEL_ID = 0x40850004 |
"Unknown Indel id requested"
| uint32 INOS_SAFECONFIG_UNKNOWN_UID = 0x40850005 |
"Unknown UID requested"
| uint32 INOS_TESTUTIL_RAMTEST_FAILED_ERR = 0x408C0002 |
"RamTest failed."
| uint32 INOS_TESTUTIL_TEST_FAILED_ERR = 0x408C0001 |
"Test failed."
| uint32 INOS_TSN_BUS_NOT_AVAILABLE = 0x408B0005 |
"TSN bus not available"
| uint32 INOS_TSN_FRAME_CHECKSUM_INVALID = 0x408B0008 |
"TSN: frame checksum invalid"
| uint32 INOS_TSN_IGMP_JOIN_FAILED = 0x408B0009 |
"TSN: failed to join multicast group"
| uint32 INOS_TSN_INVALID_FRAME_SIZE = 0x408B0003 |
"Invalid TSN frame size"
| uint32 INOS_TSN_IP_RESOLVE_FAILED = 0x408B000A |
"TSN: failed to resolve IP address"
| uint32 INOS_TSN_NOTHING_TO_RECEIVE = 0x408B0004 |
"TSN: nothing to receive"
| uint32 INOS_TSN_PAYLOAD_LIMIT_EXCEEDED = 0x408B0001 |
"TSN payload limit exceeded"
| uint32 INOS_TSN_PUBSUB_ADDRESS_INVALID = 0x408B0006 |
"TSN: PubSub address invalid"
| uint32 INOS_TSN_PUBSUB_FORMAT_INVALID = 0x408B0007 |
"TSN: PubSub format invalid"
| uint32 INOS_TSN_REMOTE_INCOMPATIBLE = 0x408B0011 |
"TSN: remote incompatible. May need INOS update."
| uint32 INOS_TSN_REMOTE_NOT_READY = 0x408B0012 |
"TSN: remote not ready. May be still booting or on error."
| uint32 INOS_TSN_REMOTE_UNREACHABLE = 0x408B0010 |
"TSN: remote unreachable"
| uint32 INOS_TSN_SEND_FAILED = 0x408B0002 |
"TSN send failed"
1.9.8
